4D Systems 4DLCD-35480320-IPS TFT TFT LCD Display, 3.5in, 320 x 480pixels
- N° de stock RS:
- 230-9323
- Référence fabricant:
- 4DLCD-35480320-IPS
- Fabricant:
- 4D Systems
Offre groupée disponible
Sous-total (1 unité)*
27,91 €
(TVA exclue)
33,77 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
En stock
- 43 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 - 4 | 27,91 € |
| 5 - 9 | 27,54 € |
| 10 + | 27,16 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 230-9323
- Référence fabricant:
- 4DLCD-35480320-IPS
- Fabricant:
- 4D Systems
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | 4D Systems | |
| Diagonal Display Size | 3.5in | |
| Interface Type | SPI | |
| Resolution | 320 x 480pixels | |
| Touch Screen | No | |
| Viewing Area Dimensions | 48.96 x 73.44mm | |
| Supply Voltage | 2.8 V | |
| Touch Screen Type | None | |
| Backlight Type | LED | |
| Display Mode | Transmissive | |
| Dimensions | 54.50 x 83.00 x 2.10mm | |
| Display Matrix Technology | TFT | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | +70°C | |
| Brightness | 320cd/m² | |
| Voltage Rating | 2.8V | |
| Viewing Area Height | 73.44mm | |
| Contrast Ratio | 1000 | |
| Number of Colours | 262K | |
| Width | 54.5mm | |
| Height | 83mm | |
| Viewing Area Width | 48.96mm | |
| Current Rating | 120mA | |
| Response Time | 30ms | |
| Power Supply Included | No | |
| Standards Met | CE, RoHS Compliant | |
| Depth | 2.1mm | |
| Display Type | TFT | |
| Series | 4DLCD | |
| Operating Temperature Range | -20 → +70°C | |
| Sélectionner tout | ||
|---|---|---|
Marque 4D Systems | ||
Diagonal Display Size 3.5in | ||
Interface Type SPI | ||
Resolution 320 x 480pixels | ||
Touch Screen No | ||
Viewing Area Dimensions 48.96 x 73.44mm | ||
Supply Voltage 2.8 V | ||
Touch Screen Type None | ||
Backlight Type LED | ||
Display Mode Transmissive | ||
Dimensions 54.50 x 83.00 x 2.10mm | ||
Display Matrix Technology TFT | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature +70°C | ||
Brightness 320cd/m² | ||
Voltage Rating 2.8V | ||
Viewing Area Height 73.44mm | ||
Contrast Ratio 1000 | ||
Number of Colours 262K | ||
Width 54.5mm | ||
Height 83mm | ||
Viewing Area Width 48.96mm | ||
Current Rating 120mA | ||
Response Time 30ms | ||
Power Supply Included No | ||
Standards Met CE, RoHS Compliant | ||
Depth 2.1mm | ||
Display Type TFT | ||
Series 4DLCD | ||
Operating Temperature Range -20 → +70°C | ||
The 4D Systems color active-matrix LCD module incorporating amorphous silicon TFT IPS (Thin Film Transistor). It is composed of a color IPSTFT-LCD panel, driver IC, FPC and a backlight unit. The module display area contains 320 x 480 pixels and can display up to 262K colors. This product accords with RoHS environmental criterion. This is a Raw TFT Display, it features no processor and cannot be programmed directly. It needs to be coupled with a Processor and circuitry capable of driving this type of display. For complete modules ready to go, please refer to our Intelligent Display Module products.
RoHS compliant
LED backlight
Operating temperature range from -20 to +70°C
This is a Non-Touch display
LED backlight
Operating temperature range from -20 to +70°C
This is a Non-Touch display
