Honeywell Technologies HAF Series Digital Airflow Sensor for Air, Gas, 0L/min Min, 200L/min Max
- N° de stock RS:
- 201-7957
- Référence fabricant:
- HAFUHH0200L4AXT
- Fabricant:
- Honeywell
Actuellement indisponible
Nous ne savons pas si cet article sera de nouveau en stock, il n'est plus vendu par le fabricant.
- N° de stock RS:
- 201-7957
- Référence fabricant:
- HAFUHH0200L4AXT
- Fabricant:
- Honeywell
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Honeywell | |
| Product Type | Airflow Sensor | |
| Media Monitored | Air, Gas | |
| Device Type | Digital | |
| Minimum Flow Rate | 0L/min | |
| Maximum Flow Rate | 200L/min | |
| Housing Material | Glass Reinforced Thermoplastic Polymer | |
| Connection Type | 6 Pin Sip Connector | |
| Maximum Pressure | 4bar | |
| Maximum Supply Voltage | 10V dc | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | No | |
| Series | HAF | |
| Current Rating | 20mA | |
| Sélectionner tout | ||
|---|---|---|
Marque Honeywell | ||
Product Type Airflow Sensor | ||
Media Monitored Air, Gas | ||
Device Type Digital | ||
Minimum Flow Rate 0L/min | ||
Maximum Flow Rate 200L/min | ||
Housing Material Glass Reinforced Thermoplastic Polymer | ||
Connection Type 6 Pin Sip Connector | ||
Maximum Pressure 4bar | ||
Maximum Supply Voltage 10V dc | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals No | ||
Series HAF | ||
Current Rating 20mA | ||
- Pays d'origine :
- CN
Honeywell HAF Series Airflow Sensor, 0 to 200L/min Maximum Flow Rate, 20mA Current - HAFUHH0200L4AXT
This Airflow sensor monitors volumetric flow of Air and gases for industrial control and process monitoring. It operates over a wide ambient range and is intended for systems requiring a Compact digital flow measurement device with low current output and modest supply voltage. The unit connects via a small-pin connector and is constructed for use where a Durable polymer housing is preferred.
Features and Benefits:
• 0 to 200 L/min range enables precise low-to-medium flow measurement
• 20 mA output supports straightforward analogue integration
• 10 VDC maximum supply allows low-voltage system compatibility
• -20°C to 70°C rating supports varied temperature environments
• 4 bar pressure tolerance permits use in pressurised lines
• 20 mA output supports straightforward analogue integration
• 10 VDC maximum supply allows low-voltage system compatibility
• -20°C to 70°C rating supports varied temperature environments
• 4 bar pressure tolerance permits use in pressurised lines
Applications
• Suitable for HVAC flow monitoring in Compact assemblies
• Ideal for pneumatic tool supply verification
• Used with control panels requiring 6‑pin SIP connector interfacing
• Can be used for gas sampling and process verification
• Suitable for industrial instrumentation where polymer housings are required
• Ideal for pneumatic tool supply verification
• Used with control panels requiring 6‑pin SIP connector interfacing
• Can be used for gas sampling and process verification
• Suitable for industrial instrumentation where polymer housings are required
What electrical Interface does it use?
It provides a digital device output with a 20 mA signal and accepts up to 10 V DC supply.
Which fluids can be measured with this device?
It is intended for monitoring Air and other gases only.
How robust is the enclosure material?
The housing is MADE from glass-reinforced thermoplastic polymer for mechanical durability.
What connector type is fitted for installation?
A 6‑pin SIP connector is provided for electrical connection.
What pressure and temperature conditions can it withstand?
It is rated to 4 bar maximum pressure and operable between -20°C and 70°C.
