Finder 58 Series Interface Relay Module, DIN Rail Mount, 230V ac Coil, 3PDT, 3-Pole, 10A Load

Voir la catégorie

Sous-total (1 unité)*

30,09 €

(TVA exclue)

36,41 €

(TVA incluse)

Add to Basket
sélectionner ou taper la quantité
Temporairement en rupture de stock
  • 3 unité(s) expédiée(s) à partir du 16 janvier 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité
Prix par unité
1 +30,09 €

*Prix donné à titre indicatif

N° de stock RS:
123-2842
Référence fabricant:
58.P3.8.230.0060SMA
Fabricant:
Finder
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout

Marque

Finder

Coil Voltage

230V ac

Contact Configuration

3PDT

Mounting Type

DIN Rail

Number of Poles

3

Series

58 Series

Load Current Rating

10A

Minimum Input Voltage

250V ac

Maximum Input Voltage

400V ac

Load Voltage Rating

250/400V ac

Switching Voltage

250 V ac → 400V ac

Terminal Type

Push In

Depth

86.3mm

Height

95.5mm

Length

31mm

Contact Material

Silver Alloy

Input Current

6mA

Turn Off Time

(dc) 15 ms, (ac) 5ms

Input Resistance

17000Ω

Dimensions

31 x 86.3 x 95.5mm

Accessory Type

Interface Relay

Relay Type

Interface Relay

Relay Switching Classification

General Purpose Relay

Maximum Operating Temperature

+70°C

Standards Met

CE, CSA, CULus, EAC, GOST, IMQ, LIoyd's Register, RINA, VDE

Special Features

AC Coils or DC Coils, Identification Label, Supply Status Indication & Coil Suppression Module as Standard

Minimum Operating Temperature

-40°C

Turn On Time

(ac) 10 ms, (dc) 10ms

Life

200000 Cycles

Operating Temperature Range

-40 → +70°C

Pays d'origine :
IT

Finder 58 Series Interface Relay Module, 230V AC Coil Voltage, 3PDT Contact Configuration - 58.P3.8.230.0060SMA


This interface relay module is designed for reliable control in various electrical applications. Operating at a coil voltage of 230V AC, it features a compact design with dimensions of 31 x 86.3 x 95.5mm. This general-purpose relay boasts a contact configuration of 3PDT, making it a versatile choice for automation and control systems.

Features & Benefits


• Enables easy integration with PLC and electronic systems
• Supports high switching capabilities of up to 10A
• Utilises push-in terminals for simplified wiring
• Operates effectively in extreme temperatures from -40°C to +70°C
• Features AC coil options and reliable supply status indication
• Complies with various international standards for safety and performance

Applications


• Utilised in panels for electrical distribution
• Integrated into packaging and textile machinery
• Ideal for use in control panels and industrial automation
• Commonly found in hoists, cranes, and wood-processing equipment

What electrical performance can be expected from this module?


It operates effectively under a load current rating of 10A and can handle switching voltages from 250V AC to 400V AC, ensuring robust performance in demanding applications.

How does the temperature range affect its operation?


The module performs optimally in temperatures ranging from -40°C to +70°C, allowing it to be used in diverse environments without risk of failure.

What is the typical lifespan of this relay module?


The electrical life at rated load is approximately 200,000 cycles, offering extensive longevity for high-demand applications.

How does the contact material influence its functionality?


The use of silver alloy contacts enhances conductivity and reliability, facilitating effective switching and minimising wear over time.
