Finder 58 Series Interface Relay, DIN Rail, 24V ac Coil, 3PDT, 53mA
- N° de stock RS:
- 123-2840
- Référence fabricant:
- 58.P3.8.024.0060SMA
- Fabricant:
- Finder
Sous-total (1 unité)*
28,88 €
(TVA exclue)
34,94 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- Plus 3 unité(s) expédiée(s) à partir du 08 juin 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 + | 28,88 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 123-2840
- Référence fabricant:
- 58.P3.8.024.0060SMA
- Fabricant:
- Finder
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Finder | |
| Coil Voltage | 24V ac | |
| Coil Resistance | 190Ω | |
| Product Type | Interface Relay | |
| Contact Configuration | 3PDT | |
| Mount Type | DIN Rail | |
| Series | 58 | |
| Terminal Type | Push-in | |
| Switching Current | 10A | |
| Switching AC Voltage | 400V ac | |
| Minimum Operating Temperature | -40°C | |
| Coil Current | 53mA | |
| Switching DC Voltage | 30V dc | |
| Contact Material | Silver Alloy | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | RoHS | |
| Length | 31mm | |
| Width | 86.3mm | |
| Height | 95.5mm | |
| Sélectionner tout | ||
|---|---|---|
Marque Finder | ||
Coil Voltage 24V ac | ||
Coil Resistance 190Ω | ||
Product Type Interface Relay | ||
Contact Configuration 3PDT | ||
Mount Type DIN Rail | ||
Series 58 | ||
Terminal Type Push-in | ||
Switching Current 10A | ||
Switching AC Voltage 400V ac | ||
Minimum Operating Temperature -40°C | ||
Coil Current 53mA | ||
Switching DC Voltage 30V dc | ||
Contact Material Silver Alloy | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals RoHS | ||
Length 31mm | ||
Width 86.3mm | ||
Height 95.5mm | ||
- Pays d'origine :
- IT
58 Series
Finder 58 series relay interface modules are an ideal interface for PLC and electronic systems.
Features and Benefits
4PCO contact configuration
Contact resistance: 50mΩ
Operating temperature range -40 to + 70°C
Dimensions: H76mm, W27mm, D73mm
Mechanical life: DC versions; 50 x 106 operations, AC versions; 20 x 106 operations
Replacement relays stock no. 385-913 etc are available (Finder 55 Series), and should be selected such that the coil voltage matches the original type
Approvals
BBJ; BEAB; CSA; DEMKO; FIMKO; GOST; NEMKO; RINA; SEMKO; SEV; UL recognised component for Canada; VDE
