Sensata / Cynergy3 Panel Reed Relay, 24 V dc Coil, SPST, 1000 V Max, 3 A Max, 780 Ω
- N° de stock RS:
- 189-2454
- Référence fabricant:
- DAR72475PU
- Fabricant:
- Sensata / Cynergy3
Sous-total (1 unité)*
55,52 €
(TVA exclue)
67,18 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
En stock
- Plus 21 unité(s) expédiée(s) à partir du 05 mars 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 + | 55,52 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 189-2454
- Référence fabricant:
- DAR72475PU
- Fabricant:
- Sensata / Cynergy3
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Sensata / Cynergy3 | |
| Product Type | Reed Relay | |
| Contact Configuration | SPST | |
| Coil Voltage | 24 V dc | |
| Mount Type | Panel | |
| Switching Current | 3 A | |
| Switching AC Voltage | 1000 V | |
| Switching DC Voltage | 1000 V | |
| Coil Power | 50W | |
| Coil Resistance | 780Ω | |
| Terminal Type | Wire Wrap | |
| Operating Time | 3ms | |
| Minimum Operating Temperature | -20°C | |
| Switching Power | 50W | |
| Maximum Operating Temperature | 70°C | |
| Series | DAR | |
| Standards/Approvals | UL | |
| Width | 15.8 mm | |
| Length | 60mm | |
| Height | 18.5mm | |
| Isolation Coil To Contact | 17kV | |
| Contact Resistance | 50mΩ | |
| Latching | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Sensata / Cynergy3 | ||
Product Type Reed Relay | ||
Contact Configuration SPST | ||
Coil Voltage 24 V dc | ||
Mount Type Panel | ||
Switching Current 3 A | ||
Switching AC Voltage 1000 V | ||
Switching DC Voltage 1000 V | ||
Coil Power 50W | ||
Coil Resistance 780Ω | ||
Terminal Type Wire Wrap | ||
Operating Time 3ms | ||
Minimum Operating Temperature -20°C | ||
Switching Power 50W | ||
Maximum Operating Temperature 70°C | ||
Series DAR | ||
Standards/Approvals UL | ||
Width 15.8 mm | ||
Length 60mm | ||
Height 18.5mm | ||
Isolation Coil To Contact 17kV | ||
Contact Resistance 50mΩ | ||
Latching No | ||
- Pays d'origine :
- GB
Very high isolation voltages (up to 10kV) are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications, such as cardiac defibrillators, test equipment and high voltage power supplies. The Rhodium contact relays have low contact resistance, while the Tungsten contact relays can switch higher voltages. PCB or Panel Mount, via Nylon studs, versions are available. Connection options, for the HV, include PCB, solder turret(wire wrap), flying lead and 0.25” spade terminals.
Choice of 10kV, 7.5kV or 5kV isolation
Low contact resistance
PCB or panel mount
HV connections via flying leads, solder turret (wire wrap), or 1/4" spade terminals
Excellent AC characteristics
