Cynergy3 PCB Reed Relay, 12V dc Coil, SPST, 1000V dc Max, 3A Max, 150 Ω
- N° de stock RS:
- 189-2207
- Référence fabricant:
- DAR71275U
- Fabricant:
- Cynergy3
Sous-total (1 boîte de 20 unités)*
1 034,18 €
(TVA exclue)
1 251,36 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Temporairement en rupture de stock
- Expédition à partir du 03 décembre 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Boîte(s) | La Boite | Prix par unité* |
|---|---|---|
| 1 + | 1 034,18 € | 51,709 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 189-2207
- Référence fabricant:
- DAR71275U
- Fabricant:
- Cynergy3
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Cynergy3 | |
| Contact Configuration | SPST | |
| Product Type | Reed Relay | |
| Mount Type | PCB | |
| Coil Power | 50W | |
| Coil Resistance | 150Ω | |
| Terminal Type | PCB Terminal | |
| Switching Power | 50W | |
| Operating Time | 3ms | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | UL | |
| Height | 18.5mm | |
| Length | 60mm | |
| Series | DAR | |
| Isolation Coil To Contact | 17kV | |
| Contact Resistance | 50mΩ | |
| Latching | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Cynergy3 | ||
Contact Configuration SPST | ||
Product Type Reed Relay | ||
Mount Type PCB | ||
Coil Power 50W | ||
Coil Resistance 150Ω | ||
Terminal Type PCB Terminal | ||
Switching Power 50W | ||
Operating Time 3ms | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals UL | ||
Height 18.5mm | ||
Length 60mm | ||
Series DAR | ||
Isolation Coil To Contact 17kV | ||
Contact Resistance 50mΩ | ||
Latching No | ||
Very high isolation voltages (up to 10kV) are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications, such as cardiac defibrillators, test equipment and high voltage power supplies. The Rhodium contact relays have low contact resistance, while the Tungsten contact relays can switch higher voltages. PCB or Panel Mount, via Nylon studs, versions are available. Connection options, for the HV, include PCB, solder turret(wire wrap), flying lead and 0.25 spade terminals.
Choice of 10kV, 7.5kV or 5kV isolation
Low contact resistance
PCB or panel mount
HV connections via flying leads, solder turret (wire wrap), or 1/4" spade terminals
Excellent AC characteristics
