Cynergy3 Panel Reed Relay, 24V dc Coil, SPST, 1000V dc Max, 3A Max, 780 Ω
- N° de stock RS:
- 189-2237
- Référence fabricant:
- DAR72475PU
- Fabricant:
- Cynergy3
Sous-total (1 boîte de 20 unités)*
1 282,93 €
(TVA exclue)
1 552,35 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Temporairement en rupture de stock
- Expédition à partir du 30 octobre 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Boîte(s) | La Boite | Prix par unité* |
|---|---|---|
| 1 + | 1 282,93 € | 64,147 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 189-2237
- Référence fabricant:
- DAR72475PU
- Fabricant:
- Cynergy3
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Cynergy3 | |
| Contact Configuration | SPST | |
| Product Type | Reed Relay | |
| Mount Type | Panel | |
| Coil Power | 50W | |
| Terminal Type | Wire Wrap | |
| Coil Resistance | 780Ω | |
| Switching Power | 50W | |
| Minimum Operating Temperature | -20°C | |
| Operating Time | 3ms | |
| Maximum Operating Temperature | 70°C | |
| Height | 18.5mm | |
| Series | DAR | |
| Length | 60mm | |
| Standards/Approvals | UL | |
| Isolation Coil To Contact | 17kV | |
| Latching | No | |
| Contact Resistance | 50mΩ | |
| Sélectionner tout | ||
|---|---|---|
Marque Cynergy3 | ||
Contact Configuration SPST | ||
Product Type Reed Relay | ||
Mount Type Panel | ||
Coil Power 50W | ||
Terminal Type Wire Wrap | ||
Coil Resistance 780Ω | ||
Switching Power 50W | ||
Minimum Operating Temperature -20°C | ||
Operating Time 3ms | ||
Maximum Operating Temperature 70°C | ||
Height 18.5mm | ||
Series DAR | ||
Length 60mm | ||
Standards/Approvals UL | ||
Isolation Coil To Contact 17kV | ||
Latching No | ||
Contact Resistance 50mΩ | ||
Very high isolation voltages (up to 10kV) are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications, such as cardiac defibrillators, test equipment and high voltage power supplies. The Rhodium contact relays have low contact resistance, while the Tungsten contact relays can switch higher voltages. PCB or Panel Mount, via Nylon studs, versions are available. Connection options, for the HV, include PCB, solder turret(wire wrap), flying lead and 0.25” spade terminals.
Choice of 10kV, 7.5kV or 5kV isolation
Low contact resistance
PCB or panel mount
HV connections via flying leads, solder turret (wire wrap), or 1/4" spade terminals
Excellent AC characteristics
