Carlo Gavazzi Plug In Timer Relay, 24 → 240 V ac, 24V dc, 2-Contact, 0.1 s → 100h, SPDT
- N° de stock RS:
- 859-3131
- Référence fabricant:
- PMB01CM24
- Fabricant:
- Carlo Gavazzi
Offre groupée disponible
Sous-total (1 unité)*
71,87 €
(TVA exclue)
86,96 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
En stock
- Plus 3 unité(s) expédiée(s) à partir du 15 décembre 2025
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 - 4 | 71,87 € |
| 5 + | 69,71 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 859-3131
- Référence fabricant:
- PMB01CM24
- Fabricant:
- Carlo Gavazzi
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Carlo Gavazzi | |
| Supply Voltage | 24 → 240 V ac, 24V dc | |
| Mounting Type | Plug In | |
| Mode of Operation | Delay ON, Delay ON Release, Double Interval, Interval, Interval On Trigger Open, Symmetrical Recycler OFF, Symmetrical Recycler ON | |
| Time Range | 0.1 s → 100h | |
| Number of Contacts | 2 | |
| Number of Timer Functions | Multi Function | |
| Contact Configuration | SPDT | |
| Time Increment | Hours, Minutes, Seconds | |
| Maximum Current | 8A | |
| Switch Configuration | SPDT | |
| Terminal Type | Plug In | |
| Power Supply | External | |
| Width | 94mm | |
| Length | 36mm | |
| Depth | 80mm | |
| Maximum Operating Temperature | +60°C | |
| Contact Material | Silver Tin Oxide | |
| Time Delay | ≤100ms | |
| Minimum Operating Temperature | -20°C | |
| Sélectionner tout | ||
|---|---|---|
Marque Carlo Gavazzi | ||
Supply Voltage 24 → 240 V ac, 24V dc | ||
Mounting Type Plug In | ||
Mode of Operation Delay ON, Delay ON Release, Double Interval, Interval, Interval On Trigger Open, Symmetrical Recycler OFF, Symmetrical Recycler ON | ||
Time Range 0.1 s → 100h | ||
Number of Contacts 2 | ||
Number of Timer Functions Multi Function | ||
Contact Configuration SPDT | ||
Time Increment Hours, Minutes, Seconds | ||
Maximum Current 8A | ||
Switch Configuration SPDT | ||
Terminal Type Plug In | ||
Power Supply External | ||
Width 94mm | ||
Length 36mm | ||
Depth 80mm | ||
Maximum Operating Temperature +60°C | ||
Contact Material Silver Tin Oxide | ||
Time Delay ≤100ms | ||
Minimum Operating Temperature -20°C | ||
Statut RoHS : Exempté
- Pays d'origine :
- IT
Carlo Gavazzi E-Mech Timer
Multi-function timers from Carlo Gavazzi provide the user with a knob-selectable timing solution which can be DIN rail mounted.
SPDT & DPDT contact configurations available
Wide power supply ranging from 24V to 240V AC/DC to ensure your application is covered
LED status indication available to provide details of relay status & power supply ON
Supports PNP/NPN and Namur sensors
Setup made simple thanks to knob selection of time range & setting
Wide power supply ranging from 24V to 240V AC/DC to ensure your application is covered
LED status indication available to provide details of relay status & power supply ON
Supports PNP/NPN and Namur sensors
Setup made simple thanks to knob selection of time range & setting
