Murata, 1400 Unshielded Surface Mount Inductor 1 mH ±10 % 2.4 A Idc Q:33
- N° de stock RS:
- 230-7872
- Référence fabricant:
- 1410524C
- Fabricant:
- Murata
Offre groupée disponible
Consulter les options de prix de grosSous-total (1 boîte de 15 unités)*
57,90 €
(TVA exclue)
70,05 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- 45 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | La Boite* |
|---|---|---|
| 15 - 30 | 3,86 € | 57,90 € |
| 45 + | 3,621 € | 54,32 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 230-7872
- Référence fabricant:
- 1410524C
- Fabricant:
- Murata
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Murata | |
| Inductance | 1mH | |
| Product Type | Surface Mount Inductor | |
| Maximum DC Current | 2.4A | |
| Package/Case | Surface Mount | |
| Length | 21.8mm | |
| Automotive Standard | No | |
| Shielding | No | |
| Minimum Operating Temperature | -40°C | |
| Maximum DC Resistance | 0.28Ω | |
| Inductance Tolerance | ±10 % | |
| Series | 1400 | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | RoHS | |
| Termination Style | Surface Mount | |
| Height | 21.8mm | |
| Depth | 29.8mm | |
| Maximum Self Resonant Frequency | 1MHz | |
| Inductor Construction | Unshielded | |
| Minimum Quality Factor | 33 | |
| Moulded | Yes | |
| Sélectionner tout | ||
|---|---|---|
Marque Murata | ||
Inductance 1mH | ||
Product Type Surface Mount Inductor | ||
Maximum DC Current 2.4A | ||
Package/Case Surface Mount | ||
Length 21.8mm | ||
Automotive Standard No | ||
Shielding No | ||
Minimum Operating Temperature -40°C | ||
Maximum DC Resistance 0.28Ω | ||
Inductance Tolerance ±10 % | ||
Series 1400 | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals RoHS | ||
Termination Style Surface Mount | ||
Height 21.8mm | ||
Depth 29.8mm | ||
Maximum Self Resonant Frequency 1MHz | ||
Inductor Construction Unshielded | ||
Minimum Quality Factor 33 | ||
Moulded Yes | ||
Statut RoHS : Exempté
The Murata bobbin inductor is 1 uH and rated current is 2.4A.Rated current (I sat) is specified when the decrease of the initial inductance value at 30%. Rated current (Item) is specified when temperature of the inductor is raised 40°C by DC current.
Bobbin inductor
High quality and low DC resistance.
Low voltage drop
High temperature stability
