KEMET 0.1F Supercapacitor -20 → +80% Tolerance, FR 5.5V dc, Through Hole
- N° de stock RS:
- 188-2093
- Référence fabricant:
- FR0H104ZF
- Fabricant:
- KEMET
Sous-total (1 paquet de 2 unités)*
7,59 €
(TVA exclue)
9,184 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
En stock
- 358 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | le paquet* |
|---|---|---|
| 2 + | 3,795 € | 7,59 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 188-2093
- Référence fabricant:
- FR0H104ZF
- Fabricant:
- KEMET
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | KEMET | |
| Capacitance | 0.1F | |
| Voltage | 5.5V dc | |
| Mounting Type | Through Hole | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
| Diameter | 14.5mm | |
| Height | 15.5mm | |
| Dimensions | 14.5 (Dia.) x 15.5mm | |
| Lead Pitch | 5.08mm | |
| Equivalent Series Resistance | 150Ω | |
| Series | FR | |
| Tolerance | -20 → +80% | |
| Product Diameter | 14.5mm | |
| Terminal Type | Radial | |
| Capacitor Family | Electric Double Layer | |
| Polarised | Polar | |
| Lead Spacing | 5.08 mm | |
| Sélectionner tout | ||
|---|---|---|
Marque KEMET | ||
Capacitance 0.1F | ||
Voltage 5.5V dc | ||
Mounting Type Through Hole | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
Diameter 14.5mm | ||
Height 15.5mm | ||
Dimensions 14.5 (Dia.) x 15.5mm | ||
Lead Pitch 5.08mm | ||
Equivalent Series Resistance 150Ω | ||
Series FR | ||
Tolerance -20 → +80% | ||
Product Diameter 14.5mm | ||
Terminal Type Radial | ||
Capacitor Family Electric Double Layer | ||
Polarised Polar | ||
Lead Spacing 5.08 mm | ||
- Pays d'origine :
- TH
FR Series Super capacitors, also known as Electric Double-Layer Capacitors (EDLCs), are intended for high energy storage applications.
Wide range of temperature from −40°C to +85°C
Maintenance free
Maximum operating voltage: 5.5 VDC
Highly reliable against liquid leakage
Lead-free
Applications
Super capacitors have characteristics ranging from traditional capacitors and batteries. As a result, Super capacitors can be used like a secondary battery when applied in a DC circuit. These devices are best suited for use in low voltage DC hold-up applications such as embedded microprocessor systems with flash memory.
Maintenance free
Maximum operating voltage: 5.5 VDC
Highly reliable against liquid leakage
Lead-free
Applications
Super capacitors have characteristics ranging from traditional capacitors and batteries. As a result, Super capacitors can be used like a secondary battery when applied in a DC circuit. These devices are best suited for use in low voltage DC hold-up applications such as embedded microprocessor systems with flash memory.
