RS PRO 3.3 F Supercapacitor -20 to 80 % Tolerance, HZ 2.7V dc, PCB
- N° de stock RS:
- 184-5043
- Fabricant:
- RS PRO
Sous-total (1 plateau de 4992 unités)*
4 068,48 €
(TVA exclue)
4 922,112 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Temporairement en rupture de stock
- Expédition à partir du 18 janvier 2027
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | le plateau* |
|---|---|---|
| 4992 + | 0,815 € | 4 068,48 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 184-5043
- Fabricant:
- RS PRO
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | RS PRO | |
| Product Type | Supercapacitor | |
| Capacitance | 3.3F | |
| Voltage | 2.7V dc | |
| Mount Type | PCB | |
| Polarity | Polar | |
| Automotive Standard | No | |
| Leakage Current | 0.05mA | |
| Equivalent Series Resistance ESR | 350mΩ | |
| Minimum Operating Temperature | -40°C | |
| Pin Count | 2 | |
| Lifetime | 200000 Cycles | |
| Maximum Operating Temperature | 70°C | |
| Series | HZ | |
| Standards/Approvals | ANSI/ESD S20.20:2014, BS EN 61340-5-1:2007 | |
| Tolerance | -20 to 80 % | |
| Capacitor Family | Electric Double Layer | |
| Sélectionner tout | ||
|---|---|---|
Marque RS PRO | ||
Product Type Supercapacitor | ||
Capacitance 3.3F | ||
Voltage 2.7V dc | ||
Mount Type PCB | ||
Polarity Polar | ||
Automotive Standard No | ||
Leakage Current 0.05mA | ||
Equivalent Series Resistance ESR 350mΩ | ||
Minimum Operating Temperature -40°C | ||
Pin Count 2 | ||
Lifetime 200000 Cycles | ||
Maximum Operating Temperature 70°C | ||
Series HZ | ||
Standards/Approvals ANSI/ESD S20.20:2014, BS EN 61340-5-1:2007 | ||
Tolerance -20 to 80 % | ||
Capacitor Family Electric Double Layer | ||
- Pays d'origine :
- CN
RS PRO EDLC Supercapacitor
The RS PRO HZ series 3.3F PCB mount EDLC supercapacitor has a voltage rating of 2.5V and leakage current (24h) of ≤0.05mA. This electric double layer capacitor is suitable for applications like general industrial equipment.
Features and Benefits
• Tolerance of -20% to 80%
• Operating temperature ranges from -40°C to 70°C
• AC impedance of 220mohm and DC impedance of 350mohm
Applications
• UPS (backup power supplies)
• Solar battery operated circuits
• Motor drives (quick charging) base stations
• Electronic meters
Certifications
• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
