Sensata / Cynergy3 PCB Reed Relay, 5 V dc Coil, SPNC, 38 Ω

N° de stock RS:: 124-5085
Référence fabricant:: DBR70510F-HR/RS
Fabricant:: Sensata / Cynergy3

Sensata / Cynergy3 PCB Reed Relay, 5 V dc Coil, SPNC, 38 Ω

Actuellement indisponible

Nous ne savons pas si cet article sera de nouveau disponible. RS a l'intention de le retirer de son assortiment sous peu.

N° de stock RS:: 124-5085
Référence fabricant:: DBR70510F-HR/RS
Fabricant:: Sensata / Cynergy3

Spécifications

Documentation technique

Législations et de normes

Détails du produit

Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.

Sélectionner tout	Attribut	Valeur
	Marque	Sensata / Cynergy3
	Product Type	Reed Relay
	Contact Configuration	SPNC
	Mount Type	PCB
	Coil Resistance	38Ω
	Minimum Operating Temperature	-20°C
	Maximum Operating Temperature	70°C
	Height	18.5mm
	Length	60mm
	Isolation Coil To Contact	17kV
	Contact Resistance	50mΩ

	Sélectionner tout
	Marque Sensata / Cynergy3
	Product Type Reed Relay
	Contact Configuration SPNC
	Mount Type PCB
	Coil Resistance 38Ω
	Minimum Operating Temperature -20°C
	Maximum Operating Temperature 70°C
	Height 18.5mm
	Length 60mm
	Isolation Coil To Contact 17kV
	Contact Resistance 50mΩ

D-HR HIGH INSULATION RESISTANCE, HIGH VOLTAGE RELAYS -5KV, 7.5KV,10KV & 15KV Series Datasheet

Cynergy3 - Reed Relay D-HR Series

Cynergy3 reed relays have high isolation voltages. These are ideal for applications such as cardiac defibrillators, test equipment and high voltage power supplies.

Features and Benefits

Low contact resistance

10kV ot 15kV isolation

Minimum insulation resistance 1 x 10¹⁴Ω

PCB or flying leads connections

Cynergy 3 - Reed Relay D-HR Series

Note

The rhodium contact relays have low contact resistance, the tungsten contact relays can switch to higher voltages.

Standards

ISO 9001
