Cynergy3 PCB Reed Relay, 5V dc Coil, SPST, 10000V dc Max, 2A Max, 16 Ω
- N° de stock RS:
- 124-5075
- Référence fabricant:
- DAT70515F-HR/RS
- Fabricant:
- Cynergy3
Sous-total (1 unité)*
95,26 €
(TVA exclue)
115,26 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Dernier stock RS
- 1 dernière(s) unité(s), prête(s) à l'envoi
Unité | Prix par unité |
|---|---|
| 1 + | 95,26 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 124-5075
- Référence fabricant:
- DAT70515F-HR/RS
- Fabricant:
- Cynergy3
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Cynergy3 | |
| Product Type | Reed Relay | |
| Contact Configuration | SPST | |
| Mount Type | PCB | |
| Coil Power | 50W | |
| Coil Resistance | 16Ω | |
| Switching Power | 50W | |
| Operating Time | 3ms | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | UL | |
| Length | 60mm | |
| Height | 18.5mm | |
| Series | DAT | |
| Isolation Coil To Contact | 17kV | |
| Latching | No | |
| Contact Resistance | 250mΩ | |
| Sélectionner tout | ||
|---|---|---|
Marque Cynergy3 | ||
Product Type Reed Relay | ||
Contact Configuration SPST | ||
Mount Type PCB | ||
Coil Power 50W | ||
Coil Resistance 16Ω | ||
Switching Power 50W | ||
Operating Time 3ms | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals UL | ||
Length 60mm | ||
Height 18.5mm | ||
Series DAT | ||
Isolation Coil To Contact 17kV | ||
Latching No | ||
Contact Resistance 250mΩ | ||
- Pays d'origine :
- GB
Cynergy3 - Reed Relay D-HR Series
Cynergy3 reed relays have high isolation voltages. These are ideal for applications such as cardiac defibrillators, test equipment and high voltage power supplies.
Features and Benefits
Low contact resistance
10kV ot 15kV isolation
Minimum insulation resistance 1 x 1014 Ω
PCB or flying leads connections
Cynergy 3 - Reed Relay D-HR Series
Note
The rhodium contact relays have low contact resistance, the tungsten contact relays can switch to higher voltages.
Standards
ISO 9001
