Cynergy3 Panel Reed Relay, 12V dc Coil, SPST, 7000V dc Max, 2A Max, 150 Ω
- N° de stock RS:
- 189-2488
- Référence fabricant:
- DAT71275PU
- Fabricant:
- Cynergy3
Actuellement indisponible
Désolés, nous ne savons pas quand ce produit sera réapprovisionné.
- N° de stock RS:
- 189-2488
- Référence fabricant:
- DAT71275PU
- Fabricant:
- Cynergy3
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Cynergy3 | |
| Product Type | Reed Relay | |
| Contact Configuration | SPST | |
| Mount Type | Panel | |
| Coil Power | 50W | |
| Terminal Type | Wire Wrap | |
| Coil Resistance | 150Ω | |
| Minimum Operating Temperature | -20°C | |
| Operating Time | 3ms | |
| Switching Power | 50W | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | UL | |
| Length | 60mm | |
| Height | 18.5mm | |
| Series | DAT | |
| Isolation Coil To Contact | 17kV | |
| Contact Resistance | 250mΩ | |
| Latching | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Cynergy3 | ||
Product Type Reed Relay | ||
Contact Configuration SPST | ||
Mount Type Panel | ||
Coil Power 50W | ||
Terminal Type Wire Wrap | ||
Coil Resistance 150Ω | ||
Minimum Operating Temperature -20°C | ||
Operating Time 3ms | ||
Switching Power 50W | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals UL | ||
Length 60mm | ||
Height 18.5mm | ||
Series DAT | ||
Isolation Coil To Contact 17kV | ||
Contact Resistance 250mΩ | ||
Latching No | ||
- Pays d'origine :
- GB
Very high isolation voltages (up to 10kV) are achieved through the use of high vacuum reed switches with either Rhodium or Tungsten contacts and make these relays suitable for high reliability applications, such as cardiac defibrillators, test equipment and high voltage power supplies. The Rhodium contact relays have low contact resistance, while the Tungsten contact relays can switch higher voltages. PCB or Panel Mount, via Nylon studs, versions are available. Connection options, for the HV, include PCB, solder turret(wire wrap), flying lead and 0.25” spade terminals.
Choice of 10kV, 7.5kV or 5kV isolation
Low contact resistance
PCB or panel mount
HV connections via flying leads, solder turret (wire wrap), or 1/4" spade terminals
Excellent AC characteristics
