Sensata / Cynergy3 PCB Reed Relay, 24 V dc Coil, SPST, 1000 V dc Max, 3 A Max, 780 Ω
- N° de stock RS:
- 124-5071
- Référence fabricant:
- DAR72410F-HR/RS
- Fabricant:
- Sensata / Cynergy3
Offre groupée disponible
Sous-total (1 unité)*
66,64 €
(TVA exclue)
80,63 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Temporairement en rupture de stock
- 20 unité(s) expédiée(s) à partir du 11 mai 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 - 24 | 66,64 € |
| 25 - 49 | 63,31 € |
| 50 - 99 | 60,11 € |
| 100 - 249 | 54,12 € |
| 250 + | 48,72 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 124-5071
- Référence fabricant:
- DAR72410F-HR/RS
- Fabricant:
- Sensata / Cynergy3
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Sensata / Cynergy3 | |
| Product Type | Reed Relay | |
| Contact Configuration | SPST | |
| Mount Type | PCB | |
| Coil Power | 50W | |
| Coil Resistance | 780Ω | |
| Minimum Operating Temperature | -20°C | |
| Switching Power | 50W | |
| Operating Time | 3ms | |
| Maximum Operating Temperature | 70°C | |
| Length | 60mm | |
| Height | 18.5mm | |
| Series | D-HR | |
| Standards/Approvals | UL | |
| Isolation Coil To Contact | 17kV | |
| Contact Resistance | 50mΩ | |
| Latching | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Sensata / Cynergy3 | ||
Product Type Reed Relay | ||
Contact Configuration SPST | ||
Mount Type PCB | ||
Coil Power 50W | ||
Coil Resistance 780Ω | ||
Minimum Operating Temperature -20°C | ||
Switching Power 50W | ||
Operating Time 3ms | ||
Maximum Operating Temperature 70°C | ||
Length 60mm | ||
Height 18.5mm | ||
Series D-HR | ||
Standards/Approvals UL | ||
Isolation Coil To Contact 17kV | ||
Contact Resistance 50mΩ | ||
Latching No | ||
Sensata Cynergy3 PCB Mount Reed Relay, 50W Switching Power, 17kV Contact Isolation - D-HR Series - DAR72410F-HR/RS
Looking for a reliable way to switch low-level signals in your electrical circuit? Choose this reed relay from Sensata Cynergy3. Its two contacts close when power is applied to the relay, switching on your electrical circuit. This unit has a long lifespan of one billion dry operations, so it performs effectively over long periods of time. A fast operating time of 3ms means it's highly responsive for rapid switching. Its contact isolation voltage of 17kV helps protect this relay against damage in the event of high voltages. You'll commonly find it used with measurement instruments and medical devices.
Features & Benefits
• Designed for PCB mounting for simple installation
• Wide operating temperature range between -20°C and +70°C for use in demanding conditions
• Compact dimensions of 60 (length) x 15.8 (width) x 18.5mm (height) to maximise packing efficiency on a PCB
What type of contacts does this reed relay have?
This reed relay's contacts are made from rhodium, which is highly conductive and has a low contact resistance. This helps to ensure a reliable electrical connection for optimal performance in demanding applications.
