Cynergy3 PCB Reed Relay, 5V dc Coil, SPST, 1000V dc Max, 3A Max, 28 Ω
- N° de stock RS:
- 124-5067
- Référence fabricant:
- DAR70510F-HR/RS
- Fabricant:
- Cynergy3
Actuellement indisponible
Nous ne savons pas si cet article sera de nouveau disponible. RS a l'intention de le retirer de son assortiment sous peu.
- N° de stock RS:
- 124-5067
- Référence fabricant:
- DAR70510F-HR/RS
- Fabricant:
- Cynergy3
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Cynergy3 | |
| Product Type | Reed Relay | |
| Contact Configuration | SPST | |
| Mount Type | PCB | |
| Coil Power | 50W | |
| Coil Resistance | 28Ω | |
| Minimum Operating Temperature | -20°C | |
| Operating Time | 3ms | |
| Switching Power | 50W | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | ISO9001CERTIFIED | |
| Length | 60mm | |
| Series | D-HR | |
| Height | 18.5mm | |
| Isolation Coil To Contact | 17kV | |
| Contact Resistance | 50mΩ | |
| Latching | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Cynergy3 | ||
Product Type Reed Relay | ||
Contact Configuration SPST | ||
Mount Type PCB | ||
Coil Power 50W | ||
Coil Resistance 28Ω | ||
Minimum Operating Temperature -20°C | ||
Operating Time 3ms | ||
Switching Power 50W | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals ISO9001CERTIFIED | ||
Length 60mm | ||
Series D-HR | ||
Height 18.5mm | ||
Isolation Coil To Contact 17kV | ||
Contact Resistance 50mΩ | ||
Latching No | ||
- Pays d'origine :
- GB
Cynergy3 - Reed Relay D-HR Series
Cynergy3 reed relays have high isolation voltages. These are ideal for applications such as cardiac defibrillators, test equipment and high voltage power supplies.
Features and Benefits
Low contact resistance
10kV ot 15kV isolation
Minimum insulation resistance 1 x 1014 Ω
PCB or flying leads connections
Cynergy 3 - Reed Relay D-HR Series
Note
The rhodium contact relays have low contact resistance, the tungsten contact relays can switch to higher voltages.
Standards
ISO 9001
