Samtec TSW Series Right Angle Through Hole Pin Header, 50 Contact(s), 2.54 mm Pitch, 1 Row, Unshrouded

N° de stock RS:: 226-3645
Référence fabricant:: TSW-150-18-L-S
Fabricant:: Samtec

Samtec TSW Series Right Angle Through Hole Pin Header, 50 Contact(s), 2.54 mm Pitch, 1 Row, Unshrouded

Informations sur le stock actuellement non accessibles

N° de stock RS:: 226-3645
Référence fabricant:: TSW-150-18-L-S
Fabricant:: Samtec

Spécifications

Documentation technique

Législations et de normes

Détails du produit

Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.

Sélectionner tout	Attribut	Valeur
	Marque	Samtec
	Product Type	Pin Header
	Series	TSW
	Pitch	2.54mm
	Housing Material	Glass Filled Polyester
	Number of Contacts	50
	Number of Rows	1
	Orientation	Right Angle
	Shrouded/Unshrouded	Unshrouded
	Mount Type	Through Hole
	Connector System	Board-to-Board
	Contact Plating	Gold
	Contact Material	Phosphor Bronze
	Termination Type	Solder
	Minimum Operating Temperature	-55°C
	Contact Gender	Male
	Maximum Operating Temperature	125°C
	Standards/Approvals	No
	Voltage	550 V

	Sélectionner tout
	Marque Samtec
	Product Type Pin Header
	Series TSW
	Pitch 2.54mm
	Housing Material Glass Filled Polyester
	Number of Contacts 50
	Number of Rows 1
	Orientation Right Angle
	Shrouded/Unshrouded Unshrouded
	Mount Type Through Hole
	Connector System Board-to-Board
	Contact Plating Gold
	Contact Material Phosphor Bronze
	Termination Type Solder
	Minimum Operating Temperature -55°C
	Contact Gender Male
	Maximum Operating Temperature 125°C
	Standards/Approvals No
	Voltage 550 V

Datasheet - TSW-150-18-L-S

The Samtec through hole sq post header standard strip has PBT insulation. Terminal is made up of phosphor bronze.

Voltage Rating up to 550 VAC mated with SSW

It is RoHS Compliant

Samtec TSW Series Right Angle Through Hole Pin Header, 50 Contact(s), 2.54 mm Pitch, 1 Row, Unshrouded
