Références fabricant

Samtec TSW Series Right Angle Through Hole Pin Header, 100 Contact(s), 2.54 mm Pitch, 2 Row, Unshrouded

N° de stock RS:: 226-3644
Référence fabricant:: TSW-150-18-L-D
Fabricant:: Samtec

Samtec TSW Series Right Angle Through Hole Pin Header, 100 Contact(s), 2.54 mm Pitch, 2 Row, Unshrouded

Informations sur le stock actuellement non accessibles

N° de stock RS:: 226-3644
Référence fabricant:: TSW-150-18-L-D
Fabricant:: Samtec

Spécifications

Documentation technique

Législations et de normes

Détails du produit

Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.

Sélectionner tout	Attribut	Valeur
	Marque	Samtec
	Product Type	Pin Header
	Series	TSW
	Pitch	2.54mm
	Housing Material	Glass Filled Polyester
	Number of Contacts	100
	Number of Rows	2
	Orientation	Right Angle
	Shrouded/Unshrouded	Unshrouded
	Mount Type	Through Hole
	Connector System	Board-to-Board
	Contact Material	Phosphor Bronze
	Contact Plating	Gold
	Minimum Operating Temperature	-55°C
	Termination Type	Solder
	Maximum Operating Temperature	125°C
	Contact Gender	Male
	Standards/Approvals	No
	Voltage	550 V

	Sélectionner tout
	Marque Samtec
	Product Type Pin Header
	Series TSW
	Pitch 2.54mm
	Housing Material Glass Filled Polyester
	Number of Contacts 100
	Number of Rows 2
	Orientation Right Angle
	Shrouded/Unshrouded Unshrouded
	Mount Type Through Hole
	Connector System Board-to-Board
	Contact Material Phosphor Bronze
	Contact Plating Gold
	Minimum Operating Temperature -55°C
	Termination Type Solder
	Maximum Operating Temperature 125°C
	Contact Gender Male
	Standards/Approvals No
	Voltage 550 V

Datasheet - TSW-150-18-L-D

The Samtec through hole sq post header standard strip has PBT insulation. Terminal is made up of phosphor bronze.

Voltage Rating up to 550 VAC mated with SSW

It is RoHS Compliant

Samtec TSW Series Right Angle Through Hole Pin Header, 100 Contact(s), 2.54 mm Pitch, 2 Row, Unshrouded
