Samtec MTMM Series Vertical Through Hole Pin Header, 4 Contact(s), 2 mm Pitch, 2 Row, Unshrouded
- N° de stock RS:
- 208-8941
- Référence fabricant:
- MTMM-102-05-T-S-295
- Fabricant:
- Samtec
Offre groupée disponible
Sous-total (1 unité)*
0,29 €
(TVA exclue)
0,35 €
(TVA incluse)
Informations sur le stock actuellement non accessibles - Veuillez vérifier plus tard
Unité | Prix par unité |
|---|---|
| 1 - 9 | 0,29 € |
| 10 - 49 | 0,28 € |
| 50 - 99 | 0,26 € |
| 100 - 249 | 0,23 € |
| 250 + | 0,20 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 208-8941
- Référence fabricant:
- MTMM-102-05-T-S-295
- Fabricant:
- Samtec
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Samtec | |
| Product Type | Pin Header | |
| Series | MTMM | |
| Pitch | 2mm | |
| Number of Contacts | 4 | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Rows | 2 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Unshrouded | |
| Connector System | Board-to-Board | |
| Mount Type | Through Hole | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold or Tin | |
| Minimum Operating Temperature | -55°C | |
| Row Pitch | 2mm | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 125°C | |
| Contact Gender | Male | |
| Standards/Approvals | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Samtec | ||
Product Type Pin Header | ||
Series MTMM | ||
Pitch 2mm | ||
Number of Contacts 4 | ||
Housing Material Liquid Crystal Polymer | ||
Number of Rows 2 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Unshrouded | ||
Connector System Board-to-Board | ||
Mount Type Through Hole | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold or Tin | ||
Minimum Operating Temperature -55°C | ||
Row Pitch 2mm | ||
Termination Type Solder | ||
Maximum Operating Temperature 125°C | ||
Contact Gender Male | ||
Standards/Approvals No | ||
The Samtec 2.00 mm of variable post height header strip has 4 contact.
Black LCP insulator material
Temperature range -55 to 125 °C
