TE Connectivity 0.6 mm Pitch 200 Way, Vertical Surface Mount Mount DDR DIMM Socket ,2.5 V, 500mA
- N° de stock RS:
- 217-5432
- Référence fabricant:
- 2040910-1
- Fabricant:
- TE Connectivity
Offre groupée disponible
Sous-total (1 unité)*
5,93 €
(TVA exclue)
7,18 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
Dernier stock RS
- 539 dernière(s) unité(s), prête(s) à l'envoi d'un autre centre de distribution
Unité | Prix par unité |
|---|---|
| 1 - 9 | 5,93 € |
| 10 + | 5,47 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 217-5432
- Référence fabricant:
- 2040910-1
- Fabricant:
- TE Connectivity
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | TE Connectivity | |
| Memory Socket Type | DIMM | |
| Product Type | DIMM Socket | |
| Insertion/Removal Method | Cam-In | |
| Orientation | Vertical | |
| Current | 500mA | |
| Contact Material | Copper Alloy | |
| Contact Plating | Gold | |
| Number of Contacts | 200 | |
| Pitch | 0.6mm | |
| Mount Type | Surface Mount | |
| Housing Material | Thermoplastic | |
| SDRAM Type | DDR | |
| Latching | No | |
| Minimum Operating Temperature | -55°C | |
| Row Spacing | 8.6mm | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | No | |
| Voltage | 2.5 V | |
| Sélectionner tout | ||
|---|---|---|
Marque TE Connectivity | ||
Memory Socket Type DIMM | ||
Product Type DIMM Socket | ||
Insertion/Removal Method Cam-In | ||
Orientation Vertical | ||
Current 500mA | ||
Contact Material Copper Alloy | ||
Contact Plating Gold | ||
Number of Contacts 200 | ||
Pitch 0.6mm | ||
Mount Type Surface Mount | ||
Housing Material Thermoplastic | ||
SDRAM Type DDR | ||
Latching No | ||
Minimum Operating Temperature -55°C | ||
Row Spacing 8.6mm | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals No | ||
Voltage 2.5 V | ||
The TE Connectivity SO DIMM Sockets, Double Data Rate (DDR), Vertical Module Orientation, Surface Mount, having 200 position with Cable-to-Board connector system.
Connector System - Cable-to-Board
Connector & Contact Terminates To - Printed Circuit Board
PCB Mounting Style - Surface Mount
