Eaton 25A 6.3 x 32 mm, Panel Cartridge Fuse Block, 250V ac
- N° de stock RS:
- 233-0601
- Référence fabricant:
- BK2-S-4202-1-R
- Fabricant:
- Eaton
Sous-total (1 boîte de 2000 unités)*
2 511,72 €
(TVA exclue)
3 039,18 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- 2 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Boîte(s) | La Boite | Prix par unité* |
|---|---|---|
| 1 + | 2 511,72 € | 1,256 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 233-0601
- Référence fabricant:
- BK2-S-4202-1-R
- Fabricant:
- Eaton
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Eaton | |
| Product Type | Fuse Block | |
| Fuse Type | Cartridge | |
| Fuse Size | 6.3 x 32 mm | |
| Number of Fuses | 1 | |
| Current Rating | 25A | |
| Voltage | 250V ac | |
| Mount Type | Panel | |
| Minimum Operating Temperature | 0°C | |
| Maximum Operating Temperature | 60°C | |
| Body Material | PA66 | |
| Standards/Approvals | UL, CE, CSA | |
| Compatible Fuse Class | Class J | |
| Dielectric Strength | 600V | |
| Series | BK2 | |
| For Use With | Class J | |
| Holder Terminal Type | Clamp | |
| Clip Material | Copper | |
| Sélectionner tout | ||
|---|---|---|
Marque Eaton | ||
Product Type Fuse Block | ||
Fuse Type Cartridge | ||
Fuse Size 6.3 x 32 mm | ||
Number of Fuses 1 | ||
Current Rating 25A | ||
Voltage 250V ac | ||
Mount Type Panel | ||
Minimum Operating Temperature 0°C | ||
Maximum Operating Temperature 60°C | ||
Body Material PA66 | ||
Standards/Approvals UL, CE, CSA | ||
Compatible Fuse Class Class J | ||
Dielectric Strength 600V | ||
Series BK2 | ||
For Use With Class J | ||
Holder Terminal Type Clamp | ||
Clip Material Copper | ||
- Pays d'origine :
- TW
Eaton BK2 Series Fuse Block, 25A Current Rating, 250V AC Voltage - BK2-S-4202-1-R
This fuse Block is a single-position holder designed to accommodate Class J fuses in panel-mounted electrical assemblies. It provides a secure mounting solution for overcurrent protection in control panels and equipment, enabling straightforward replacement of fuses while supporting typical industrial operating environments.
Features and Benefits:
• 25A current rating for moderate-duty circuit protection • 250V AC working voltage suitable for standard AC systems • Clamp-style terminals ensure tight conductor connection • PA66 body offers electrical insulation and mechanical stability • Copper clip material for consistent electrical contact • Dielectric strength rated 600V to resist breakdown
Applications
• Suitable for protection circuits in automation control panels • Ideal for power distribution modules in electrical switchgear • Used with Class J fuses in industrial machinery protection • Can be used for maintenance replacement in retrofit projects • Used for panel-mounted overcurrent devices in factories
What temperature range can it operate within safely?
It is rated to operate between 0°C and 60°C, so it should be installed where ambient temperatures remain within this range.
How many fuses does a single unit accommodate?
Each unit holds one fuse, designed for straightforward single-circuit protection.
What mounting arrangement is required for installation?
It is designed for panel mounting and is secured to panels using its intended mounting interface.
Which standards has it been assessed against for acceptance?
It carries UL, CE and CSA approvals, indicating conformity with those inspection and safety frameworks.
What fuse size is compatible with the holder?
The holder accepts 6.3 x 32mm fuses compatible with the specified Class J family.
Note
Eaton formerly known as Bussmann
