Name: Eaton 10A 6.3 x 32 mm, Panel Cartridge Fuse Block, 250V ac
Brand: Eaton
SKU: 233-0613
Price: 3990.97 EUR
Availability: BackOrder

Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.

Sélectionner tout	Attribut	Valeur
	Marque	Eaton
	Product Type	Fuse Block
	Fuse Type	Cartridge
	Fuse Size	6.3 x 32 mm
	Number of Fuses	1
	Current Rating	10A
	Voltage	250V ac
	Mount Type	Panel
	Minimum Operating Temperature	0°C
	Maximum Operating Temperature	60°C
	Body Material	Phenolic
	Standards/Approvals	CE, UL, CSA
	Dielectric Strength	600V
	Series	BK4
	Compatible Fuse Class	Class J
	For Use With	Class J
	Holder Terminal Type	Clamp
	Clip Material	Brass

	Sélectionner tout
	Marque Eaton
	Product Type Fuse Block
	Fuse Type Cartridge
	Fuse Size 6.3 x 32 mm
	Number of Fuses 1
	Current Rating 10A
	Voltage 250V ac
	Mount Type Panel
	Minimum Operating Temperature 0°C
	Maximum Operating Temperature 60°C
	Body Material Phenolic
	Standards/Approvals CE, UL, CSA
	Dielectric Strength 600V
	Series BK4
	Compatible Fuse Class Class J
	For Use With Class J
	Holder Terminal Type Clamp
	Clip Material Brass

Pays d'origine :: TW

Eaton BK4 Series Fuse Block, 10A Current Rating, 250V AC Voltage - BK4-S-4004-1-R

This fuse Block provides a secure single-fuse mounting solution for panel installations in industrial and control environments. It is designed to accept Class J fuses in a Compact format and to perform reliably within typical electrical distribution and equipment protection systems.

Features and Benefits:

• Rated for 10 A current to protect low-power circuits • 250V AC rating for moderate-voltage applications • Clamp Terminal ensures solid electrical connection • Phenolic laminate body for electrical insulation performance • Brass clip offers corrosion-resistant conductor contact • Dielectric strength 600V to resist electrical breakdown

Applications

• Suitable for industrial control panel fuse protection • Ideal for automation equipment requiring Class J fuses • Used with distribution modules in electrical enclosures • Can be used for maintenance spares in mechanical systems

What ambient temperatures can it operate within?

It is specified for operation between 0°C and 60°C to suit typical indoor industrial environments.

How is the component mounted in an enclosure?

It is intended for panel mounting, allowing integration into control and distribution panels.

What fuse size does it accept?

It accommodates fuses with a 6.3 x 32mm footprint compatible with the Class J form factor.

Which materials contribute to its electrical safety?

The insulating body is phenolic laminate and conductive parts are brass, providing dielectric isolation and dependable contact performance.

Are there recognised standards associated with the design?

The unit meets CE, UL and CSA approvals applicable to its construction and use.

Note

Eaton formerly known as Bussmann
