ifm electronic SM Series Magnetic Inductive Flow Meter Flow Sensor for Liquid, 0.1L/min Min, 25L/min Max
- N° de stock RS:
- 191-652
- Référence fabricant:
- SM6100
- Fabricant:
- ifm electronic
Sous-total (1 unité)*
683,70 €
(TVA exclue)
827,28 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- Plus 2 unité(s) expédiée(s) à partir du 17 août 2026
- Plus 2 unité(s) expédiée(s) à partir du 26 août 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 + | 683,70 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 191-652
- Référence fabricant:
- SM6100
- Fabricant:
- ifm electronic
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | ifm electronic | |
| Product Type | Flow Sensor | |
| Media Monitored | Liquid | |
| Device Type | Magnetic Inductive Flow Meter | |
| Minimum Flow Rate | 0.1L/min | |
| Maximum Flow Rate | 25L/min | |
| Housing Material | 316L Stainless Steel | |
| Maximum Pressure | 16bar | |
| Minimum Media Temperature | -10°C | |
| Maximum Supply Voltage | 30V | |
| IP Rating | IP67, IP65 | |
| Minimum Operating Temperature | 0°C | |
| Maximum Media Temperature | 70°C | |
| Maximum Operating Temperature | 80°C | |
| Series | SM | |
| Standards/Approvals | DIN EN 60068-2-6, DIN EN 60068-2-27, UL, DIN EN 60947-5-9 | |
| Current Rating | 20mA | |
| Sélectionner tout | ||
|---|---|---|
Marque ifm electronic | ||
Product Type Flow Sensor | ||
Media Monitored Liquid | ||
Device Type Magnetic Inductive Flow Meter | ||
Minimum Flow Rate 0.1L/min | ||
Maximum Flow Rate 25L/min | ||
Housing Material 316L Stainless Steel | ||
Maximum Pressure 16bar | ||
Minimum Media Temperature -10°C | ||
Maximum Supply Voltage 30V | ||
IP Rating IP67, IP65 | ||
Minimum Operating Temperature 0°C | ||
Maximum Media Temperature 70°C | ||
Maximum Operating Temperature 80°C | ||
Series SM | ||
Standards/Approvals DIN EN 60068-2-6, DIN EN 60068-2-27, UL, DIN EN 60947-5-9 | ||
Current Rating 20mA | ||
- Pays d'origine :
- DE
The ifm electronic Magnetic Inductive Flow Meter is designed for industrial applications, featuring gold plated contacts for enhanced durability. It supports a totalizer function and is suited for measuring conductive liquids, including water and hydrous media. The meter requires a minimum media conductivity of 20 μS/cm and can handle viscosities up to 70 mm²/s at 40°C. It features a minimum insulation resistance of 100 MOhm at 500 V DC and includes reverse polarity protection. The meter has a power on delay time of 5 seconds and employs a magnetic-inductive measuring principle for accurate flow measurement.
Precise measurement of flow
Precise measurement of consumption and medium temperature
High accuracy
High repeatability and measurement dynamics
With switching output
Analogue output and pulse output
Clearly visible 4-digit LED display
Convenient operation via buttons or parameter setting via IO-Link
