Phoenix Contact CUC Series RJ45 Connector Female, Rear Straight 1 Port
- N° de stock RS:
- 281-626
- Référence fabricant:
- 1414396
- Fabricant:
- Phoenix Contact
Offre groupée disponible
Consulter les options de prix de grosSous-total (1 unité)*
44,69 €
(TVA exclue)
54,07 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Stocké-e par le fabricant
- Prêt à être expédié à partir du 22 janvier 2027
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 - 9 | 44,69 € |
| 10 + | 41,11 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 281-626
- Référence fabricant:
- 1414396
- Fabricant:
- Phoenix Contact
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Phoenix Contact | |
| Ethernet Connector Type | RJ45 | |
| Product Type | RJ45 Connector | |
| Number of Ports | 1 | |
| Mount Type | Rear | |
| Connector Gender | Female | |
| Connector Type | M12 | |
| Orientation | Straight | |
| IP Rating | IP65, IP67 | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 85°C | |
| Hazardous Area Certification | No | |
| Standards/Approvals | UL, cUL, RoHS | |
| Series | CUC | |
| Contact Material | Copper Alloy | |
| Sélectionner tout | ||
|---|---|---|
Marque Phoenix Contact | ||
Ethernet Connector Type RJ45 | ||
Product Type RJ45 Connector | ||
Number of Ports 1 | ||
Mount Type Rear | ||
Connector Gender Female | ||
Connector Type M12 | ||
Orientation Straight | ||
IP Rating IP65, IP67 | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 85°C | ||
Hazardous Area Certification No | ||
Standards/Approvals UL, cUL, RoHS | ||
Series CUC | ||
Contact Material Copper Alloy | ||
- Pays d'origine :
- DE
The Phoenix Contact control cabinet feed through is an M12, 8 position, A-coded connector with an RJ45 socket, featuring a 180° socket input. It offers IP65 and IP67 protection, ensuring durability and resistance to dust and water.
Designed to meet the rigorous safety standards for rail vehicles
Manufactured with shock and vibration resistance for enhanced reliability
Supports fast coding with a specially designed plastic profile
Simple installation process requiring no load or voltage during operation
Ensures safety with required guide pins and socket use to prevent misalignment
