Finder 48 Series Interface Relay, DIN Rail Mount, 24V ac Coil, DPDT-2C/0, 2-Pole, 8A Load
- N° de stock RS:
- 123-2813
- Référence fabricant:
- 48.P5.8.024.0060SPA
- Fabricant:
- Finder
Sous-total (1 unité)*
18,91 €
(TVA exclue)
22,88 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
- 3 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Unité | Prix par unité |
|---|---|
| 1 + | 18,91 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 123-2813
- Référence fabricant:
- 48.P5.8.024.0060SPA
- Fabricant:
- Finder
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Finder | |
| Coil Voltage | 24V ac | |
| Contact Configuration | DPDT-2C/0 | |
| Mounting Type | DIN Rail | |
| Series | 48 Series | |
| Number of Poles | 2 | |
| Load Current Rating | 8A | |
| Maximum Input Voltage | 400V ac | |
| Minimum Input Voltage | 250V ac | |
| Terminal Type | Push In | |
| Switching Voltage | 250 V ac → 400V ac | |
| Depth | 75.3mm | |
| Height | 95.5mm | |
| Length | 15.8mm | |
| Contact Material | Silver Alloy | |
| Input Current | 46mA | |
| Special Features | AC Coils or DC Sensitive Coils, Identification Label, Supply Status Indication & EMC Coil Suppression Module as Standard | |
| Standards Met | CE, CSA, CULus, EAC, EZU, GOST, IMQ, LCIE, LIoyd's Register, RINA, VDE | |
| Relay Switching Classification | General Purpose Relay | |
| Maximum Operating Temperature | +70°C | |
| Minimum Operating Temperature | -40°C | |
| Turn Off Time | (dc) 12 ms, (ac) 4ms | |
| Operating Temperature Range | -40 → +70°C | |
| Turn On Time | (dc) 12 ms, (ac) 7ms | |
| Dimensions | 15.8 x 75.3 x 95.5mm | |
| Sélectionner tout | ||
|---|---|---|
Marque Finder | ||
Coil Voltage 24V ac | ||
Contact Configuration DPDT-2C/0 | ||
Mounting Type DIN Rail | ||
Series 48 Series | ||
Number of Poles 2 | ||
Load Current Rating 8A | ||
Maximum Input Voltage 400V ac | ||
Minimum Input Voltage 250V ac | ||
Terminal Type Push In | ||
Switching Voltage 250 V ac → 400V ac | ||
Depth 75.3mm | ||
Height 95.5mm | ||
Length 15.8mm | ||
Contact Material Silver Alloy | ||
Input Current 46mA | ||
Special Features AC Coils or DC Sensitive Coils, Identification Label, Supply Status Indication & EMC Coil Suppression Module as Standard | ||
Standards Met CE, CSA, CULus, EAC, EZU, GOST, IMQ, LCIE, LIoyd's Register, RINA, VDE | ||
Relay Switching Classification General Purpose Relay | ||
Maximum Operating Temperature +70°C | ||
Minimum Operating Temperature -40°C | ||
Turn Off Time (dc) 12 ms, (ac) 4ms | ||
Operating Temperature Range -40 → +70°C | ||
Turn On Time (dc) 12 ms, (ac) 7ms | ||
Dimensions 15.8 x 75.3 x 95.5mm | ||
- Pays d'origine :
- IT
48 Series
Features and Benefits
Mechanical life: AC versions; 10 x 106 operations, DC versions; 20 x 106 operations
Dimensions: H78.6mm, W15.8mm, D76mm
Instant ejection of relay using plastic retaining clip
Supply status indication and EMC coil suppression module
Push-in and screw terminals
Approvals
