Wurth Elektronik 16 MHz Crystal ±30.00 ppm SMT 4-Pin 2.5 mm 3.2 mm 2.5mm
- N° de stock RS:
- 197-579
- Référence fabricant:
- 830107878109
- Fabricant:
- Wurth Elektronik
Sous-total (1 bobine de 3000 unités)*
1 359,00 €
(TVA exclue)
1 644,00 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Temporairement en rupture de stock
- Expédition à partir du 22 juin 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | la bobine* |
|---|---|---|
| 3000 + | 0,453 € | 1 359,00 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 197-579
- Référence fabricant:
- 830107878109
- Fabricant:
- Wurth Elektronik
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Wurth Elektronik | |
| Standard Frequency | 16MHz | |
| Product Type | Crystal | |
| Mount Type | Surface Mount | |
| Load Capacitance | 12pF | |
| Packaging | Tape & Reel | |
| Package Type | SMT | |
| Pin Count | 4 | |
| Length | 3.2mm | |
| Width | 2.5mm | |
| Height | 2.5mm | |
| Frequency Tolerance | ±30.00 ppm | |
| Minimum Operating Temperature | -40°C | |
| Frequency Stability | ±50 ppm | |
| Series Resistance | 70Ω | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | REACH, RoHS, MIL-STD-202F | |
| Series | CFPX-180 | |
| Automotive Standard | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Wurth Elektronik | ||
Standard Frequency 16MHz | ||
Product Type Crystal | ||
Mount Type Surface Mount | ||
Load Capacitance 12pF | ||
Packaging Tape & Reel | ||
Package Type SMT | ||
Pin Count 4 | ||
Length 3.2mm | ||
Width 2.5mm | ||
Height 2.5mm | ||
Frequency Tolerance ±30.00 ppm | ||
Minimum Operating Temperature -40°C | ||
Frequency Stability ±50 ppm | ||
Series Resistance 70Ω | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals REACH, RoHS, MIL-STD-202F | ||
Series CFPX-180 | ||
Automotive Standard No | ||
- Pays d'origine :
- CN
The Wurth Elektronik Standard SMD crystal is designed for high performance and reliability in a Compact design. The 3.2 x 2.5mm ceramic package features a seam sealed metal lid, ensuring robustness and protection against environmental factors. Furthermore, with features such as hermetic sealing and compliance with RoHS standards, you can Trust this crystal to meet stringent industry requirements while offering exceptional longevity and performance.
Wide operating temperature range supports varied application scenarios
Low drive level minimizes power consumption in electronic circuits
Suitable for fundamental overtone applications enhances versatility
Shock and vibration resistant for enhanced reliability in harsh conditions
