ABB Auxiliary Contact, 2 Contact, 2 NO, EH04-20N, Side, 6 A, 500V, 1SAE901901R1020

Voir la catégorie

Sous-total (1 unité)*

33,92 €

(TVA exclue)

41,04 €

(TVA incluse)

Add to Basket
sélectionner ou taper la quantité
En stock
  • 4 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité
Prix par unité
1 +33,92 €

*Prix donné à titre indicatif

N° de stock RS:
211-1476
Référence fabricant:
1SAE901901R1020
Fabricant:
ABB
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout

Marque

ABB

Product Type

Auxiliary Contact

Number of Contacts

2

Normal State Configuration

2 NO

Series

EH04-20N

Mount Type

Side

Contact Current

6A

Terminal Type

Screw

Pole and Throw Configuration

DPST

Contact Voltage

500V

Rated Insulation Voltage Ui

500V

Operational Current Ie

6A

Mounting Location

Side Mounting

Minimum Operating Temperature

-25°C

Maximum Operating Temperature

55°C

Standards/Approvals

No

Pays d'origine :
BG

ABB EH04-20N Series Auxiliary Contact, 6A Operational Current, 500V Rated Insulation Voltage - 1SAE901901R1020


This auxiliary contact is a side-mounted switching accessory designed to extend the signalling and control capabilities of installation contactors in electrical panels. It provides additional changeover functionality for AC auxiliary circuits at supply frequencies used in industrial automation, enabling clear state indication and auxiliary switching without modifying the main contactor.

Features & Benefits


• 2NO configuration adds two independent normally open contacts for signalling
• Rated insulation voltage500V supports higher-voltage control circuits
• Conventional thermal current6A permits modest auxiliary loads
• Screw Terminal connections enable secure wiring with stranded conductors
• DPST arrangement supplies two-pole switching for dual-circuit control
• Operational range -25°C to55°C suits typical plant ambient conditions

**Applications**


• Suitable for expanding contactor control circuits in factory automation
• Used with installation contactors to provide remote status signalling
• Ideal for integration into control panels requiring two-pole auxiliary switching
• Can be used for motor starter interlocks and control logic feedback

What mounting method is required for installation?


It fits to the side of compatible installation contactors and secures without tools during assembly.

Which conductor sizes are supported on the terminals?


Top and bottom terminals accept single and dual conductors

common capacities include 1x1.5mm², 1x2.5–4mm² and 2x1.5mm² for typical panel wiring.

How does the device behave under transient overvoltage?


The unit is specified with a rated impulse withstand of4kV, providing resilience against standard transient events in control circuits.

Are there torque recommendations for Terminal fastening?


Tightening torque values are provided for reliable electrical contact and vary by Terminal type, with auxiliary circuit torques specified for correct clamping.
