DiodesZetex AP7583AQ-50D4-13, 1-Channel Low Noise LDO, Regulator, 300 mA, 7 V, MSOP-8EP 8-Pin
- N° de stock RS:
- 216-332
- Référence fabricant:
- AP7583AQ-50D4-13
- Fabricant:
- DiodesZetex
Offre groupée disponible
Sous-total (1 unité)*
0,79 €
(TVA exclue)
0,96 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
En stock
- 2 500 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 - 9 | 0,79 € |
| 10 - 99 | 0,71 € |
| 100 - 499 | 0,66 € |
| 500 - 999 | 0,60 € |
| 1000 + | 0,54 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 216-332
- Référence fabricant:
- AP7583AQ-50D4-13
- Fabricant:
- DiodesZetex
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | DiodesZetex | |
| Product Type | Regulator | |
| Regulator Type | Low Noise LDO | |
| Output Voltage | 7 V | |
| Number of Outputs | 1 | |
| Line Regulation | 10 mV | |
| Load Regulation | 20 mV | |
| Polarity | Positive | |
| Quiescent Current | 3μA | |
| Package Type | MSOP-8EP | |
| Output Current | 300mA | |
| Pin Count | 8 | |
| Switching Regulator | No | |
| Series | AP7583 | |
| Height | 1.1mm | |
| Length | 4.9mm | |
| Width | 3 mm | |
| Standards/Approvals | Pb-Free, RoHS | |
| Maximum Input Voltage | 42V | |
| Minimum Input Voltage | 3V | |
| Maximum Operating Temperature | 125°C | |
| Minimum Operating Temperature | -40°C | |
| Automotive Standard | AEC-Q100 | |
| Sélectionner tout | ||
|---|---|---|
Marque DiodesZetex | ||
Product Type Regulator | ||
Regulator Type Low Noise LDO | ||
Output Voltage 7 V | ||
Number of Outputs 1 | ||
Line Regulation 10 mV | ||
Load Regulation 20 mV | ||
Polarity Positive | ||
Quiescent Current 3μA | ||
Package Type MSOP-8EP | ||
Output Current 300mA | ||
Pin Count 8 | ||
Switching Regulator No | ||
Series AP7583 | ||
Height 1.1mm | ||
Length 4.9mm | ||
Width 3 mm | ||
Standards/Approvals Pb-Free, RoHS | ||
Maximum Input Voltage 42V | ||
Minimum Input Voltage 3V | ||
Maximum Operating Temperature 125°C | ||
Minimum Operating Temperature -40°C | ||
Automotive Standard AEC-Q100 | ||
- Pays d'origine :
- CN
The DiodesZetex Voltage Regulators are 300mA LDO for automotive battery powered applications. It features 2.5μA quiescent current at light loads. Therefore, it suitable solution to supply always power on components, such as microcontroller and controller area network transceivers. The IC consists of a voltage reference, an error amplifier, a resistor network for setting output voltage, a current limit circuit for current protection, and a chip enable circuit.
Compatible with low ESR ceramic capacitor
Thermal shutdown function
Short current protection function
Output current limit
Totally lead free and fully RoHS compliant
Halogen and antimony free
