Festo Vacuum Pump, 0.95 mm nozzle, 3.5 bar 21.8 L/min, VN series
- N° de stock RS:
- 203-6302
- Référence fabricant:
- VN-10-H-T3-PI4-VI4-RO1-A
- Fabricant:
- Festo
Sous-total (1 unité)*
117,60 €
(TVA exclue)
142,30 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- 1 unité(s) prête(s) à être expédiée(s)
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 + | 117,60 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 203-6302
- Référence fabricant:
- VN-10-H-T3-PI4-VI4-RO1-A
- Fabricant:
- Festo
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Festo | |
| Product Type | Vacuum Pump | |
| Maximum Suction Flow | 21.8L/min | |
| Maximum Vacuum Pressure | 3.5bar | |
| Nozzle Diameter | 0.95mm | |
| Series | VN | |
| Silencer | Yes | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | RoHS, ISO8573-1:2010 (7:4:4) | |
| Hazardous Area Certification | No | |
| Outlet Port Size | 1/8 in G | |
| Sélectionner tout | ||
|---|---|---|
Marque Festo | ||
Product Type Vacuum Pump | ||
Maximum Suction Flow 21.8L/min | ||
Maximum Vacuum Pressure 3.5bar | ||
Nozzle Diameter 0.95mm | ||
Series VN | ||
Silencer Yes | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals RoHS, ISO8573-1:2010 (7:4:4) | ||
Hazardous Area Certification No | ||
Outlet Port Size 1/8 in G | ||
- Pays d'origine :
- HU
Festo Series VN Vacuum Pump, 21.8L/min Maximum Suction Flow, 3.5 Bar Maximum Vacuum Pressure - VN-10-H-T3-PI4-VI4-RO1-A, Numeric Part Number: 532642
This vacuum pump is a Compact pneumatic unit designed to generate suction for automation and handling tasks in industrial settings. It operates as a small, purpose-built pump suitable for integration into control systems where moderate vacuum and steady flow are required, and it includes a sound-dampening element for quieter operation.
Features and Benefits:
• Maximum suction flow 21.8 L/min delivers steady handling performance • Maximum vacuum pressure 3.5 bar enables firm workpiece grip • Nozzle diameter 0.95mm supports precision pick-and-place • Outlet port 1/8 in G simplifies connection to pneumatic lines • Rated for continuous use up to 60 °C for demanding environments • Silencer fitted to reduce acoustic emissions during operation
Applications
• Suitable for pick-and-place in Electronic Assembly lines • Ideal for small-part handling in mechanical workshops • Used with vacuum grippers in automated packaging systems • Can be used for PCB component placement and testing rigs • Used for suction-based part transfer in electrical panel assembly
What approvals or environmental standards does it meet?
It conforms to RoHS restrictions and adheres to particulate and oil/water classes per ISO 8573-1:2010 indicated as 7:4:4.
How does the silencer affect installation options?
The integrated silencer permits installation nearer to workstations where lower noise is necessary without additional muffling hardware.
What operating limits should be observed for reliable performance?
Continuous operation should not exceed the specified maximum ambient temperature of 60 °C to maintain rated performance.
How does the outlet Interface with existing pneumatic systems?
The outlet uses a 1/8 in G threaded connection compatible with standard pneumatic fittings common in automation installations.
