RS PRO Clamp Mount Timer Relay, 10 → 30V dc, 1-Contact, 1-Function, NC, SPST
- N° de stock RS:
- 798-3448
- Fabricant:
- RS PRO
3 En stock, livraison sous 1 jour(s) (stock Europe)
36 En stock, livraison sous 3 à 5 jours (stock Europe)
Ajouté
Prix la pièce
95,00 €
(TVA exclue)
114,95 €
(TVA incluse)
| Unité | Prix par unité |
| 1 - 4 | 95,00 € |
| 5 - 9 | 91,20 € |
| 10 + | 87,40 € |
- N° de stock RS:
- 798-3448
- Fabricant:
- RS PRO
Législations et de normes
- Pays d'origine :
- TR
Détails du produit
RS PRO Single-function Timer Relay
The RS PRO single-function timer relay performs the function of providing interval delay in the range between 0.1 second and 10 hours. It is a compact digital equipment with high precision and accuracy to suit a wide variety of applications. This can be installed into new and existing applications without much hassle.
Features and Benefits
- 1 SPNO 1 C/O contact configuration
- The supply voltage rating is between 10VDC to 30VDC
- 4-digit LED display
- Operation with one set value
- Single contact output for timing control (ON/OFF)
- External start input
- Start and stop possibility by front panel
- Set value high limit boundaries
- Display can be adjusted to show second, minute and hour
- Programmable time bases (second, minute, hour)
- Adjustable internal buzzer according to timer stop status
- Password protection for programming section
- Panel mount
Applications
- Textiles
- Chemical industry
- Mining
- Irrigation
- Raw material handling
- Food and beverages
- Industrial process control
- Package machines
- Quality control rollers
- Filling systems
- Tool benches
- Building automation
- Production bands
Certifications
IP65 rated (front panel)
IP20 rated (protection at rear)
IP40 rated
CE certified
IP20 rated (protection at rear)
IP40 rated
CE certified
RS PRO
RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards; they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
Spécifications
Attribut | Valeur |
|---|---|
| Supply Voltage | 10 → 30V dc |
| Mounting Type | Clamp |
| Mode of Operation | Interval |
| Number of Contacts | 1 |
| Number of Timer Functions | Single |
| Contact Configuration | NC, SPST |
| Time Increment | Hours, Minutes, Seconds |
| Maximum Voltage | 30V dc |
| Switch Configuration | DPDT |
| Power Supply | External |
| Width | 65mm |
| Minimum Voltage | 10V dc |
| Depth | 34.5mm |
| Length | 76mm |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -30°C |
