Infineon SRAM- 16 MB
- N° de stock RS:
- 273-5284
- Référence fabricant:
- CY62167EV30LL-45BVXI
- Fabricant:
- Infineon
Offre groupée disponible
Sous-total (1 unité)*
11,18 €
(TVA exclue)
13,53 €
(TVA incluse)
Ajouter 7 unités pour bénéficier d'une livraison gratuite
En stock
- 77 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 - 9 | 11,18 € |
| 10 - 24 | 10,36 € |
| 25 - 49 | 9,77 € |
| 50 + | 9,53 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 273-5284
- Référence fabricant:
- CY62167EV30LL-45BVXI
- Fabricant:
- Infineon
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Infineon | |
| Memory Size | 16MB | |
| Product Type | SRAM | |
| Organisation | 1M x 16 bit, 2M x 8 bit | |
| Number of Words | 1000 k, 2000 k | |
| Number of Bits per Word | 16 | |
| Maximum Random Access Time | 45ns | |
| Minimum Supply Voltage | 0.3V | |
| Maximum Supply Voltage | 3.9V | |
| Mount Type | Surface | |
| Minimum Operating Temperature | -40°C | |
| Package Type | TSOP I | |
| Maximum Operating Temperature | 85°C | |
| Pin Count | 48 | |
| Standards/Approvals | RoHS | |
| Height | 12mm | |
| Length | 20mm | |
| Width | 1.05 mm | |
| Series | CY62167EV30 | |
| Supply Current | 35mA | |
| Sélectionner tout | ||
|---|---|---|
Marque Infineon | ||
Memory Size 16MB | ||
Product Type SRAM | ||
Organisation 1M x 16 bit, 2M x 8 bit | ||
Number of Words 1000 k, 2000 k | ||
Number of Bits per Word 16 | ||
Maximum Random Access Time 45ns | ||
Minimum Supply Voltage 0.3V | ||
Maximum Supply Voltage 3.9V | ||
Mount Type Surface | ||
Minimum Operating Temperature -40°C | ||
Package Type TSOP I | ||
Maximum Operating Temperature 85°C | ||
Pin Count 48 | ||
Standards/Approvals RoHS | ||
Height 12mm | ||
Length 20mm | ||
Width 1.05 mm | ||
Series CY62167EV30 | ||
Supply Current 35mA | ||
The Infineon SRAM is a high performance CMOS static RAM organized as 1M words by 16 bits or 2M words by 8 bits. This device features an Advanced circuit design that provides an ultra low Active current. Ultra low Active current is Ideal for providing More Battery Life in portable applications such as cellular telephones. The device also has an automatic power down feature that reduces power consumption by 99 percent when addresses are not toggling.
Very high speed
Ultra low Active power
Ultra low standby power
CMOS for optimum speed and power
Automatic power down when deselected
