Omron PY08 8 Way PCB Relay Socket, for use with Miniature Power Relays
- N° de stock RS:
- 264-7452
- Référence fabricant:
- PY08
- Fabricant:
- Omron
Sous-total (1 unité)*
2,12 €
(TVA exclue)
2,57 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- 26 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 + | 2,12 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 264-7452
- Référence fabricant:
- PY08
- Fabricant:
- Omron
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Omron | |
| Product Type | Relay Socket | |
| For Use With | Miniature Power Relays | |
| Current | 7A | |
| Series | PY08 | |
| Terminal Type | Solder | |
| Standards/Approvals | UL 508, RoHS, CSA | |
| Mount Type | PCB | |
| Number of Contacts | 8 | |
| Sélectionner tout | ||
|---|---|---|
Marque Omron | ||
Product Type Relay Socket | ||
For Use With Miniature Power Relays | ||
Current 7A | ||
Series PY08 | ||
Terminal Type Solder | ||
Standards/Approvals UL 508, RoHS, CSA | ||
Mount Type PCB | ||
Number of Contacts 8 | ||
Omron PY08 Series Relay Socket, 7A Current Rating, 8 Contacts - PY08
This relay socket provides a PCB-mounted Interface for miniature power relays, enabling secure electrical connection and soldered termination for printed circuit board assemblies. It is designed for control and switching contexts within automation and electronics systems, offering a Compact 8-contact arrangement and compatibility with industry-standard miniature relay packages.
Features and Benefits:
• Rated for 7A continuous current handling for moderate loads
• Eight solder terminals for robust PCB electrical connections
• PCB mounting style for low-profile board integration
• UL508 and RoHS approvals supporting regulated installations
• CSA recognition for conformity with electrical safety practices
• Eight solder terminals for robust PCB electrical connections
• PCB mounting style for low-profile board integration
• UL508 and RoHS approvals supporting regulated installations
• CSA recognition for conformity with electrical safety practices
Applications
• Suitable for relay-based control panels in factory automation
• Ideal for signal switching on industrial control PCBs
• Used with miniature power relays in motor-control circuits
• Can be used for prototyping and small-production PCB assemblies
• Ideal for signal switching on industrial control PCBs
• Used with miniature power relays in motor-control circuits
• Can be used for prototyping and small-production PCB assemblies
What Terminal connection method does it use for PCB assembly?
Termination is by soldered pins designed to be routed through PCB holes and soldered on the reverse for permanent electrical and mechanical attachment.
How many electrical contact points are available for relay wiring?
It provides eight individual contact positions to match common 8-pin miniature relay footprints and associated circuits.
Is it appropriate for use in regulated industrial equipment?
The component carries UL508 and CSA recognition and conforms to RoHS restrictions, aligning it with many industrial regulatory requirements.
What current loads can the socket manage during normal operation?
The socket is specified to handle currents up to 7A, suitable for moderate power switching tasks on control boards.
