Cynergy3 Panel Reed Relay, 24V dc Coil, SPNC, 1000V dc Max, 3A Max, 925 Ω
- N° de stock RS:
- 189-2457
- Référence fabricant:
- DBR72405PU
- Fabricant:
- Cynergy3
Actuellement indisponible
Désolés, nous ne savons pas quand ce produit sera réapprovisionné.
- N° de stock RS:
- 189-2457
- Référence fabricant:
- DBR72405PU
- Fabricant:
- Cynergy3
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Cynergy3 | |
| Product Type | Reed Relay | |
| Contact Configuration | SPNC | |
| Mount Type | Panel | |
| Coil Power | 50W | |
| Coil Resistance | 925Ω | |
| Terminal Type | Wire Wrap | |
| Minimum Operating Temperature | -20°C | |
| Switching Power | 50W | |
| Operating Time | 2ms | |
| Maximum Operating Temperature | 70°C | |
| Height | 18.5mm | |
| Standards/Approvals | UR | |
| Series | DBR | |
| Length | 60mm | |
| Isolation Coil To Contact | 17kV | |
| Latching | No | |
| Contact Resistance | 50mΩ | |
| Sélectionner tout | ||
|---|---|---|
Marque Cynergy3 | ||
Product Type Reed Relay | ||
Contact Configuration SPNC | ||
Mount Type Panel | ||
Coil Power 50W | ||
Coil Resistance 925Ω | ||
Terminal Type Wire Wrap | ||
Minimum Operating Temperature -20°C | ||
Switching Power 50W | ||
Operating Time 2ms | ||
Maximum Operating Temperature 70°C | ||
Height 18.5mm | ||
Standards/Approvals UR | ||
Series DBR | ||
Length 60mm | ||
Isolation Coil To Contact 17kV | ||
Latching No | ||
Contact Resistance 50mΩ | ||
- Pays d'origine :
- GB
Very high isolation voltages (up to 10kV) are achieved through the use of high vacuum reed switches with Tungsten or Rhodium contacts and make these relays suitable for high reliability applications, such as cardiac defibrillators, test equipment and high voltage power supplies. The Tungsten contact relays can switch high voltages, up to 7000Vdc/ac peak to peak PCB or Panel Mount, via Nylon studs, versions are available. Connection options, for the HV, include PCB, solder turret(wire wrap), flying lead and 0.25” spade terminals.
Choice of 10kV, 7.5kV or 5kV isolation
Low contact resistance
PCB or panel mount
HV connections via flying leads, solder turret (wire wrap), or 1/4" spade terminals
Excellent AC characteristics
