Arcolectric (Bulgin) Ltd MP0045/1E1 Series Illuminated Push Button Switch, Latching, Panel, 16.2 mm Cutout, DPDT, Amber

N° de stock RS:: 187-3305
Référence fabricant:: MP0045/1E1AM220S
Fabricant:: Arcolectric (Bulgin) Ltd

Arcolectric (Bulgin) Ltd MP0045/1E1 Series Illuminated Push Button Switch, Latching, Panel, 16.2 mm Cutout, DPDT, Amber

Sous-total (1 plateau de 40 unités)*

1 318,64 €

(TVA exclue)

1 595,56 €

(TVA incluse)

Frais de livraison offerts pour toute commande de plus de 90,00 €

Temporairement en rupture de stock

Expédition à partir du 26 novembre 2026

Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails

Unité	Prix par unité	le plateau*
40 +	32,966 €	1 318,64 €

*Prix donné à titre indicatif

N° de stock RS:: 187-3305
Référence fabricant:: MP0045/1E1AM220S
Fabricant:: Arcolectric (Bulgin) Ltd

Spécifications

Documentation technique

Législations et de normes

Détails du produit

Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.

Sélectionner tout	Attribut	Valeur
	Marque	Arcolectric (Bulgin) Ltd
	Product Type	Push Button Switch
	Actuator Colour	Silver
	Switch Operation	Latching
	Illuminated	Yes
	Panel Cutout Size	16.2 mm
	Series	MP0045/1E1
	Mount Type	Panel
	Contact Configuration	DPDT
	Terminal Type	Solder
	LED Colour	Amber
	IP Rating	IP67
	Contact AC Voltage	250V ac
	Contact DC Voltage	220V dc
	Minimum Operating Temperature	-20°C
	Actuator Style	Round
	Maximum Operating Temperature	55°C
	Switch Configuration	DPCO
	Switch Contact Current	3A
	Standards/Approvals	RoHS
	Legend	Blank

	Sélectionner tout
	Marque Arcolectric (Bulgin) Ltd
	Product Type Push Button Switch
	Actuator Colour Silver
	Switch Operation Latching
	Illuminated Yes
	Panel Cutout Size 16.2 mm
	Series MP0045/1E1
	Mount Type Panel
	Contact Configuration DPDT
	Terminal Type Solder
	LED Colour Amber
	IP Rating IP67
	Contact AC Voltage 250V ac
	Contact DC Voltage 220V dc
	Minimum Operating Temperature -20°C
	Actuator Style Round
	Maximum Operating Temperature 55°C
	Switch Configuration DPCO
	Switch Contact Current 3A
	Standards/Approvals RoHS
	Legend Blank

Datasheet MP0045/1E1AM220S

Pays d'origine :: CN

Bulgin MP0045/1E1 Series Push Button Switch, 250V AC Voltage Rating, 16.2mm Panel Cut Out Diameter - MP0045/1E1AM220S

This push button switch is designed for panel mounting, featuring a round chrome design and an illuminated amber LED indicator for enhanced visibility. With a panel cut-out diameter of 16.2mm, this latching push button switch is built to operate under demanding conditions, certified with an IP67 rating for dust and water resistance. It remains functional over a temperature range of -20 to +55°C, making it suitable for various applications in automation and industrial settings.

Features & Benefits

• Latching operation ensures a consistent state until manually switched

• Illuminated with an amber LED for clear status indication

• Robust IP67 rating protects against dust and water ingress

• Designed for panel mounting for easy installation

• DPDT contact configuration allows versatile control options

• Constructed with brass contacts for durability and performance

Applications

• Used for machine control in industrial automation

• Suitable for electronic equipment panels

• Ideal for harsh environments requiring water and dust resistance

• Utilised in control panels where clear status indication is essential

What is the minimum and maximum operating temperature for this switch?

The switch operates effectively within a minimum temperature of –20°C and a maximum of +55°C, making it versatile for various environmental conditions.

How does the IP67 rating benefit this switch?

The IP67 rating signifies complete protection against dust and temporary immersion in water, ensuring reliable performance in challenging environments.

What type of terminals does this switch come with?

It features solder tag terminals, allowing for secure and long-lasting connections in electronic applications.

Can this switch handle alternating and direct current?

Yes, it is rated for a maximum contact AC voltage of 250V and DC voltage of 220V, suitable for different electrical systems.

What contact current rating does this switch offer?

This model can handle a contact current rating of 3A, making it effective for various electrical loads.
