Norgren Pneumatic Regulator -, Without Yoke 0.3 bar R64G
- N° de stock RS:
- 184-4435
- Référence fabricant:
- R64G-NNK-RMN
- Fabricant:
- Norgren
Offre groupée disponible
Sous-total (1 unité)*
154,80 €
(TVA exclue)
187,31 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
En stock
- Plus 15 unité(s) expédiée(s) à partir du 02 mars 2026
- Plus 22 unité(s) expédiée(s) à partir du 02 mars 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 - 4 | 154,80 € |
| 5 - 9 | 150,01 € |
| 10 + | 145,20 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 184-4435
- Référence fabricant:
- R64G-NNK-RMN
- Fabricant:
- Norgren
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Norgren | |
| Product Type | Pneumatic Regulator | |
| Series | R64G | |
| Outlet Size | Without Yoke | |
| Material | Zinc Alloy | |
| Maximum Operating Temperature | 80°C | |
| Standards/Approvals | No | |
| Minimum Operating Pressure | 0.3bar | |
| Sélectionner tout | ||
|---|---|---|
Marque Norgren | ||
Product Type Pneumatic Regulator | ||
Series R64G | ||
Outlet Size Without Yoke | ||
Material Zinc Alloy | ||
Maximum Operating Temperature 80°C | ||
Standards/Approvals No | ||
Minimum Operating Pressure 0.3bar | ||
Statut RoHS : Exempté
- Pays d'origine :
- CZ
IMI Norgren Pneumatic Regulator, 0.3 to 10 Bar Outlet Pressure, R64G Series - R64G-NNK-RMN
This IMI Norgren pneumatic regulator is a high-flow pressure-reducing valve that controls and maintains output pressures in your compressed-air applications. Wide operating temperatures ranging from -20°C to +80°C make it suitable for use with demanding applications in harsh ambient conditions. You can mount the unit in any position according to your setup and operational specifications. It responds quickly to varying pressures to provide reliable regulation and prevent the loss of pressurised energy.
Features & Benefits
• Zinc body and aluminium bonnet withstand corrosion and make the unit robust and durable
• Synthetic rubber seals ensure an airtight component to prevent the unnecessary loss of compressed air
• Brass valves contain very low levels of lead, for use in the food and beverage industries
Applications
• Gas grills
• Heating furnaces
• Industrial applications
• Cyclic testing machinery
How does a pneumatic regulator work?
A pneumatic regulator controls pressures by automatically disconnecting gas or liquid flow when the system reaches a pre-set pressure. The unit often uses wire coil springs to perform this function.
How do I choose the right pneumatic regulator?
Size is the first consideration in choosing a pneumatic regulator, as an incorrect fit will result in wasted energy.
