Samtec EW Series Straight Through Hole Pin Header, 50 Contact(s), 2.54 mm Pitch, 1 Row, Unshrouded
- N° de stock RS:
- 277-9758
- Référence fabricant:
- EW5014LS900
- Fabricant:
- Samtec
Offre groupée disponible
Sous-total (1 sachet de 4 unités)*
25,20 €
(TVA exclue)
30,48 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
En stock
- 24 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
- Plus 28 unité(s) expédiée(s) à partir du 29 décembre 2025
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | Le Sachet* |
|---|---|---|
| 4 - 76 | 6,30 € | 25,20 € |
| 80 - 296 | 5,238 € | 20,95 € |
| 300 - 1196 | 4,413 € | 17,65 € |
| 1200 - 2396 | 4,093 € | 16,37 € |
| 2400 + | 3,785 € | 15,14 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 277-9758
- Référence fabricant:
- EW5014LS900
- Fabricant:
- Samtec
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Samtec | |
| Series | EW | |
| Product Type | Pin Header | |
| Current | 3A | |
| Pitch | 2.54mm | |
| Housing Material | Black Glass Filled Polyester | |
| Number of Contacts | 50 | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Unshrouded | |
| Mount Type | Through Hole | |
| Connector System | Board-to-Board | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold | |
| Row Pitch | 2.54mm | |
| Minimum Operating Temperature | -55°C | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 125°C | |
| Tail Pin Length | 8.38mm | |
| Contact Gender | Male | |
| Mating Pin Length | 5.08mm | |
| Standards/Approvals | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Samtec | ||
Series EW | ||
Product Type Pin Header | ||
Current 3A | ||
Pitch 2.54mm | ||
Housing Material Black Glass Filled Polyester | ||
Number of Contacts 50 | ||
Number of Rows 1 | ||
Orientation Straight | ||
Shrouded/Unshrouded Unshrouded | ||
Mount Type Through Hole | ||
Connector System Board-to-Board | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold | ||
Row Pitch 2.54mm | ||
Minimum Operating Temperature -55°C | ||
Termination Type Solder | ||
Maximum Operating Temperature 125°C | ||
Tail Pin Length 8.38mm | ||
Contact Gender Male | ||
Mating Pin Length 5.08mm | ||
Standards/Approvals No | ||
EW Series 2.54mm Through Hole Board Stackers
Single row
2 stacker heights (distance between boards) available
Supplied in bags containing 4 board stackers
Contact material: Phosphor Bronze
Plating: gold contact (longest tail), remainder tin
Accepts 0.64mm square pins for board to board applications
2.54mm Board to Board and Wire to Board - Samtec
