HARWIN M20 Series Vertical Surface Pin Header, 6 Contact(s), 2.54 mm Pitch, 1 Row, Unshrouded
- N° de stock RS:
- 247-9125
- Référence fabricant:
- M20-8770642R
- Fabricant:
- HARWIN
Offre groupée disponible
Consulter les options de prix de grosSous-total (1 ruban de 5 unités)*
3,87 €
(TVA exclue)
4,685 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- 165 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | le ruban* |
|---|---|---|
| 5 - 20 | 0,774 € | 3,87 € |
| 25 - 45 | 0,684 € | 3,42 € |
| 50 + | 0,618 € | 3,09 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 247-9125
- Référence fabricant:
- M20-8770642R
- Fabricant:
- HARWIN
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | HARWIN | |
| Series | M20 | |
| Product Type | Pin Header | |
| Pitch | 2.54mm | |
| Current | 3A | |
| Housing Material | Thermoplastic | |
| Number of Contacts | 6 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Unshrouded | |
| Connector System | Board-to-Board | |
| Mount Type | Surface | |
| Contact Material | Brass | |
| Contact Plating | Gold | |
| Row Pitch | 2.54mm | |
| Minimum Operating Temperature | 105°C | |
| Termination Type | Solder | |
| Maximum Operating Temperature | -40°C | |
| Contact Gender | Male | |
| Standards/Approvals | UL | |
| Mating Pin Length | 5mm | |
| Sélectionner tout | ||
|---|---|---|
Marque HARWIN | ||
Series M20 | ||
Product Type Pin Header | ||
Pitch 2.54mm | ||
Current 3A | ||
Housing Material Thermoplastic | ||
Number of Contacts 6 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Unshrouded | ||
Connector System Board-to-Board | ||
Mount Type Surface | ||
Contact Material Brass | ||
Contact Plating Gold | ||
Row Pitch 2.54mm | ||
Minimum Operating Temperature 105°C | ||
Termination Type Solder | ||
Maximum Operating Temperature -40°C | ||
Contact Gender Male | ||
Standards/Approvals UL | ||
Mating Pin Length 5mm | ||
Statut RoHS : Exempté
- Pays d'origine :
- TW
The HARWIN PCB connectors has contact pitch of 2.54 mm and have 0.64 mm square pins and sockets suitable for interconnecting board to board and board to wire. The plug pin is held in a moulding and is available for either horizontal or vertical, surface mount or through board solder mounting.
Contact gender male/plug
Connector orientation vertical
Connection type surface mount
Mating pin size 0.64mm square
