Samtec FTSH Series Straight Through Hole Pin Header, 10 Contact(s), 1.27 mm Pitch, 2 Row, Unshrouded
- N° de stock RS:
- 180-3002
- Référence fabricant:
- FTSH-105-01-L-DV-K-TR
- Fabricant:
- Samtec
Offre groupée disponible
Sous-total (1 unité)*
2,27 €
(TVA exclue)
2,75 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
En stock
- 145 unité(s) prête(s) à être expédiée(s)
- Plus 57 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 - 24 | 2,27 € |
| 25 - 99 | 2,09 € |
| 100 - 249 | 1,92 € |
| 250 - 499 | 1,79 € |
| 500 + | 1,67 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 180-3002
- Référence fabricant:
- FTSH-105-01-L-DV-K-TR
- Fabricant:
- Samtec
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Samtec | |
| Product Type | Pin Header | |
| Series | FTSH | |
| Pitch | 1.27mm | |
| Current | 3.4A | |
| Number of Contacts | 10 | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Rows | 2 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Unshrouded | |
| Connector System | Wire-to-Board | |
| Mount Type | Through Hole | |
| Contact Plating | Gold | |
| Contact Material | Phosphor Bronze | |
| Minimum Operating Temperature | -55°C | |
| Row Pitch | 1.27mm | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 125°C | |
| Contact Gender | Male | |
| Tail Pin Length | 0.1mm | |
| Mating Pin Length | 3.05mm | |
| Standards/Approvals | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Samtec | ||
Product Type Pin Header | ||
Series FTSH | ||
Pitch 1.27mm | ||
Current 3.4A | ||
Number of Contacts 10 | ||
Housing Material Liquid Crystal Polymer | ||
Number of Rows 2 | ||
Orientation Straight | ||
Shrouded/Unshrouded Unshrouded | ||
Connector System Wire-to-Board | ||
Mount Type Through Hole | ||
Contact Plating Gold | ||
Contact Material Phosphor Bronze | ||
Minimum Operating Temperature -55°C | ||
Row Pitch 1.27mm | ||
Termination Type Solder | ||
Maximum Operating Temperature 125°C | ||
Contact Gender Male | ||
Tail Pin Length 0.1mm | ||
Mating Pin Length 3.05mm | ||
Standards/Approvals No | ||
Samtec FTSH Pin Header, Straight, 1.27mm Pitch - FTSH-105-01-L-DV-K-TR
This pin header by Samtec is a straight wire to board connector with a 1.27mm pitch. This pin header is suitable for various electronic applications.
Features & Benefits
• Made with phosphor bronze contact material for durability
• Gold plated for enhanced signal transmission
• Surface mount design for easy installation
• Consists of 10 pins in 2 rows for efficient connectivity
• Unshrouded for versatility
• Solder termination for secure connections
Applications
• Ideal for use in PCBs requiring a wire to board connection
• Suitable for electronic devices in automation systems
• Can be used for creating circuits in electrical equipment
Can it be used for high-current applications?
Yes, it has a current rating of 3.4A, making it suitable for various power requirements.
Will it work with PCBs of different thicknesses?
It is designed for surface mount and can be used with various PCB thicknesses.
Is it compatible with other Samtec products?
Yes, it is part of the FTSH series, ensuring compatibility with other products in the range.
