Samtec HTSW Series Pin Header, 2 Contact(s), 2.54 mm Pitch, 1 Row, Unshrouded
- N° de stock RS:
- 180-1221
- Référence fabricant:
- HTSW-102-07-S-S
- Fabricant:
- Samtec
Sous-total (1 sachet de 6370 unités)*
1 006,46 €
(TVA exclue)
1 216,67 €
(TVA incluse)
Informations sur le stock actuellement non accessibles - Veuillez vérifier plus tard
Unité | Prix par unité | Le Sachet* |
|---|---|---|
| 6370 + | 0,158 € | 1 006,46 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 180-1221
- Référence fabricant:
- HTSW-102-07-S-S
- Fabricant:
- Samtec
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Samtec | |
| Product Type | Pin Header | |
| Series | HTSW | |
| Pitch | 2.54mm | |
| Number of Contacts | 2 | |
| Number of Rows | 1 | |
| Shrouded/Unshrouded | Unshrouded | |
| Connector System | Board-to-Board | |
| Contact Plating | Gold | |
| Contact Material | Phosphor Bronze | |
| Termination Type | Through Hole | |
| Tail Pin Length | 2.54mm | |
| Mating Pin Length | 5.84mm | |
| Sélectionner tout | ||
|---|---|---|
Marque Samtec | ||
Product Type Pin Header | ||
Series HTSW | ||
Pitch 2.54mm | ||
Number of Contacts 2 | ||
Number of Rows 1 | ||
Shrouded/Unshrouded Unshrouded | ||
Connector System Board-to-Board | ||
Contact Plating Gold | ||
Contact Material Phosphor Bronze | ||
Termination Type Through Hole | ||
Tail Pin Length 2.54mm | ||
Mating Pin Length 5.84mm | ||
Contact System: .025" (0.635 mm) square post
Orientation: Vertical, right-angle
Pitch: .100" (2.54 mm)
Special Features: Suitable for most high-temperature board processing
Termination: Through-hole
