SICK DBS60E Series Incremental Incremental Encoder 27V, 1024 ppr ppr, Push Pull, HTL Signal, Solid Shaft Type, 8 mm

N° de stock RS:: 285-1087
Référence fabricant:: DBS60E-TGEK01024 / 1072093
Fabricant:: SICK

Sous-total (1 unité)*

248,50 €

(TVA exclue)

300,68 €

(TVA incluse)

Frais de livraison offerts pour toute commande de plus de 90,00 €

Stocké-e par le fabricant

Prêt à être expédié à partir du 11 décembre 2026

Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails

Unité	Prix par unité
1 +	248,50 €

*Prix donné à titre indicatif

N° de stock RS:: 285-1087
Référence fabricant:: DBS60E-TGEK01024 / 1072093
Fabricant:: SICK

Spécifications

Documentation technique

Législations et de normes

Détails du produit

Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.

Sélectionner tout	Attribut	Valeur
	Marque	SICK
	Product Type	Incremental Encoder
	Encoder Technology	Incremental
	Series	DBS60E
	Pulses Per Revolution	1024ppr
	Output Signal Type	Push Pull, HTL
	Shaft Type	Solid Shaft
	Shaft Diameter	8mm
	Interface Type	Incremental
	IP Rating	IP65
	Terminal Type	Cable
	Maximum Supply Voltage	27V
	Minimum Operating Temperature	-20°C
	Overall Height	60mm
	Standards/Approvals	UK declaration of conformity, EU declaration of conformity, cULus, CHINA-RoHS, CE, ACMA declaration of conformity
	Overall Width	60mm
	Mount Type	Flange
	Maximum Operating Temperature	85°C
	Switching Frequency	300kHz

	Sélectionner tout
	Marque SICK
	Product Type Incremental Encoder
	Encoder Technology Incremental
	Series DBS60E
	Pulses Per Revolution 1024ppr
	Output Signal Type Push Pull, HTL
	Shaft Type Solid Shaft
	Shaft Diameter 8mm
	Interface Type Incremental
	IP Rating IP65
	Terminal Type Cable
	Maximum Supply Voltage 27V
	Minimum Operating Temperature -20°C
	Overall Height 60mm
	Standards/Approvals UK declaration of conformity, EU declaration of conformity, cULus, CHINA-RoHS, CE, ACMA declaration of conformity
	Overall Width 60mm
	Mount Type Flange
	Maximum Operating Temperature 85°C
	Switching Frequency 300kHz

Datasheet - DBS60E-TGEK01024

Pays d'origine :: MY

Overview

The DBS60 is a rugged incremental encoder with a 60 mm diameter and small installation depth. The device comes in an aluminium or stainless-steel housing and offers lots of mechanical interfaces. The DBS60 Inox variants can even withstand harsh ambient conditions due their fully stainless steel design and rugged shaft seal. The IP69K DBS60I-W variant with its patented deflector screen is the ideal solution for applications in washdown environments. In addition to the interfaces for TTL and HTL.

The DBS60 also offers two universal interfaces with a wide voltage range. Due to the high enclosure rating, rugged design, and a resolution of up to 10,000 pulses per resolution, the DBS60 is suitable for applications in many different industries.

At a glance

Pulses per revolution: Up to 10,000

Housing diameter: 60 mm

Solid shaft, blind hollow shaft, and through hollow shaft

Enclosure rating: IP67, IP69K

Communication interfaces: TTL/RS-422, HTL/Push Pull, universal interface (TTL, HTL)

Connection type: M12 or M23 male connector, cable, cable with M12 or M23 male connector

Stainless steel or aluminium housing

Your Benefit

Various installation options and connection types allow flexible cabling

Compact housing dimensions save valuable space

With its insulated hollow shafts, the encoder is protected against damage from any eddy currents or higher temperatures transmitted by the shaft

Stainless steel housing provides corrosion protection against environmental influences

Protection against water ingress with IP enclosure rating up to IP69K

Reliable operation in harsh wash down environments with hot water and high pressure in the food and beverages industry

Applications

Fields of applications

Measurement of position, speed and displacement in factory and logistics automation, e.g., in storage and transport logistics, the food and beverages industry, medical technology, at ports and offshore plants, asynchronous motors, e
