Sélectionner tout	Attribut	Valeur
	Marque	Renesas Electronics
	Family Name	RX210
	Package Type	TFLGA
	Mounting Type	Surface Mount
	Pin Count	100
	Device Core	RX
	Data Bus Width	32bit
	Program Memory Size	128 kB
	Maximum Frequency	50MHz
	RAM Size	20 kB
	USB Channels	0
	Number of PWM Units	0
	Typical Operating Supply Voltage	1.62 → 5.5 V
	Dimensions	7 x 7 x 1.05mm
	Minimum Operating Temperature	-40 °C
	Maximum Operating Temperature	+85 °C
	Program Memory Type	Flash
	Number of ADC Units	1
	Length	7mm
	ADCs	1 (16 x 12 bit)
	Height	1.05mm
	Instruction Set Architecture	CISC Harvard
	Width	7mm

	Sélectionner tout
	Marque Renesas Electronics
	Family Name RX210
	Package Type TFLGA
	Mounting Type Surface Mount
	Pin Count 100
	Device Core RX
	Data Bus Width 32bit
	Program Memory Size 128 kB
	Maximum Frequency 50MHz
	RAM Size 20 kB
	USB Channels 0
	Number of PWM Units 0
	Typical Operating Supply Voltage 1.62 → 5.5 V
	Dimensions 7 x 7 x 1.05mm
	Minimum Operating Temperature -40 °C
	Maximum Operating Temperature +85 °C
	Program Memory Type Flash
	Number of ADC Units 1
	Length 7mm
	ADCs 1 (16 x 12 bit)
	Height 1.05mm
	Instruction Set Architecture CISC Harvard
	Width 7mm

Pays d'origine :: JP

RX210 Microcontrollers

The RX210 family of 32-bit low power microcontrollers supports large capacity memory and up to 78DMIPS calculation speed.

• 50MHz 32-bit RX core microcontroller
• Up to 1MB Flash memory
• 32-bit multiplier/divider with multiply-accumulate
• 4-channel DMA controller (DMACA)
• Data transfer controller (DTCa)
• Event link controller (ELC)
• Temperature sensor
• Clock Frequency Accuracy Measurement Circuit
• Data Operation Circuit
• 14-bit Independent Watchdog Timer
• ADC self-diagnostic function
• CRC Calculator

Renesas Electronics, 32bit RX, RX210 Microcontroller, 50MHz, 128 kB Flash, 100-Pin TFLGA
