ifm electronic KQ Series Capacitive Electronic Level Sensor, Housing Polybutylene Terephthalate, Polycarbonate
- N° de stock RS:
- 185-403
- Référence fabricant:
- KQ1000
- Fabricant:
- ifm electronic
Sous-total (1 unité)*
280,90 €
(TVA exclue)
339,89 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Temporairement en rupture de stock
- 1 unité(s) expédiée(s) à partir du 10 juin 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 + | 280,90 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 185-403
- Référence fabricant:
- KQ1000
- Fabricant:
- ifm electronic
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | ifm electronic | |
| Device Type | Capacitive | |
| Product Type | Electronic Level Sensor | |
| Housing Material | Polybutylene Terephthalate, Polycarbonate | |
| Cable Length | 2m | |
| Minimum Operating Temperature | -20°C | |
| Interface Type | IO-Link | |
| Maximum Operating Temperature | 80°C | |
| Maximum DC Voltage | 30V dc | |
| Maximum Current | 50mA | |
| Standards/Approvals | EN 60068-2-6 5 g (10.2000 Hz), 230 - 1 GHz 47 dBμV/m QP/10 m distance, ± 2.5 kV/100 kHz, DIN EN 61000-4-2 ± 25 kV AD/± 25 kV CD, DIN EN 61000-4-3 80 MHz/1 GHz 10 V/m, DIN EN 61000-4-4 ± 2.5 kV/5 kHz, DIN EN 61000-4-6 10 V, DIN EN 61000-6-4 30 - 230 MHz 40 dBμV/m QP/10 m distance, EN 60068-2-27 15 g 11 ms, IEC 61131-9 | |
| Series | KQ | |
| Hazardous Area Certification | No | |
| Sélectionner tout | ||
|---|---|---|
Marque ifm electronic | ||
Device Type Capacitive | ||
Product Type Electronic Level Sensor | ||
Housing Material Polybutylene Terephthalate, Polycarbonate | ||
Cable Length 2m | ||
Minimum Operating Temperature -20°C | ||
Interface Type IO-Link | ||
Maximum Operating Temperature 80°C | ||
Maximum DC Voltage 30V dc | ||
Maximum Current 50mA | ||
Standards/Approvals EN 60068-2-6 5 g (10.2000 Hz), 230 - 1 GHz 47 dBμV/m QP/10 m distance, ± 2.5 kV/100 kHz, DIN EN 61000-4-2 ± 25 kV AD/± 25 kV CD, DIN EN 61000-4-3 80 MHz/1 GHz 10 V/m, DIN EN 61000-4-4 ± 2.5 kV/5 kHz, DIN EN 61000-4-6 10 V, DIN EN 61000-6-4 30 - 230 MHz 40 dBμV/m QP/10 m distance, EN 60068-2-27 15 g 11 ms, IEC 61131-9 | ||
Series KQ | ||
Hazardous Area Certification No | ||
- Pays d'origine :
- DE
The ifm electronic continuous level sensor uses capacitive technology for precise measurement in non-metallic and non-conductive environments. Its compact design (250 x 28 x 16.7mm) facilitates easy installation in tight spaces, while IO-Link communication enhances integration and flexibility. Equipped with protective features like reverse polarity and overload protection, this sensor ensures reliable performance for both bulk materials and liquids.
Continuous level measurement behind non-metallic and non-conductive surfaces
No stress caused by the medium thanks to non-contact detection
Three point level sensors in one unit
Deposits can be detected and signalled to improve quality of the process
Link
