RS PRO 3.4 V White LED 5 mm Through Hole
- N° de stock RS:
- 254-5722
- Fabricant:
- RS PRO
Sous-total (1000 unités, dans un sac de 1000)*
109,00 €
(TVA exclue)
132,00 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- 21 000 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | Le Sachet* |
|---|---|---|
| 1000 + | 0,109 € | 109,00 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 254-5722
- Fabricant:
- RS PRO
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | RS PRO | |
| LED Colour | White | |
| Product Type | LED | |
| Maximum Forward Current | 100mA | |
| Package Type | 5 mm | |
| Packaging | Anti-Electrostatic Bag | |
| Mount Type | Through Hole | |
| Number of LEDs | 1 | |
| Forward Voltage | 3.4V | |
| Maximum Power Dissipation | 85mW | |
| Number of Pins | 2 | |
| Viewing Angle | 15 ° | |
| LED Luminous Flux | 32900 to 43000 mcd | |
| Lens Dimensions | 5 mm (White LED Round with Flange) | |
| LED Luminosity | 32900 → 43000mcd | |
| Colour Rendering Index CRI | 80% | |
| Lens Shape | Round | |
| Standards/Approvals | RoHS Compliant | |
| Colour Temperature | 10000K | |
| Lens Colour | Clear | |
| Automotive Standard | No | |
| Sélectionner tout | ||
|---|---|---|
Marque RS PRO | ||
LED Colour White | ||
Product Type LED | ||
Maximum Forward Current 100mA | ||
Package Type 5 mm | ||
Packaging Anti-Electrostatic Bag | ||
Mount Type Through Hole | ||
Number of LEDs 1 | ||
Forward Voltage 3.4V | ||
Maximum Power Dissipation 85mW | ||
Number of Pins 2 | ||
Viewing Angle 15 ° | ||
LED Luminous Flux 32900 to 43000 mcd | ||
Lens Dimensions 5 mm (White LED Round with Flange) | ||
LED Luminosity 32900 → 43000mcd | ||
Colour Rendering Index CRI 80% | ||
Lens Shape Round | ||
Standards/Approvals RoHS Compliant | ||
Colour Temperature 10000K | ||
Lens Colour Clear | ||
Automotive Standard No | ||
- Pays d'origine :
- CN
RS PRO White LED (5mm)
A reliable and robust White LED (Light Emitting Diode) specifically designed for applications requiring a higher level of brightness. This LED features a phosphor filled reflector to convert the normally blue emission of the InGaN chip to a perfect white for a clear and highly visible light.;Designed for through hole mounting the LED is easy to mount with minimum soldering using the 2 general purpose leads and at 5mm the round LED lens is bright enough to be viewed from distance.;With a luminous intensity of 43000mcd and a long service life this LED provides a bright and stable performance no matter the ambient light or time of day. Ideal for use in applications that require a high level of visibility such as status indication.
Features and Benefits
Standards: ROHS compliant, EU REACH compliant
Why RS PRO?
Looking to reduce costs but keep the same quality? ;With a choice of over 65,000 products – all of which are rigorously tested against demanding industry standards before they are given the RS PRO seal of approval.;Trusted by engineers the world over, we want you to be confident that you’re receiving the exceptional quality, reliability and the best value for money.
