1296.2012 Mentor GmbH Press-In 20-Way Right Angle Rigid LED Light Pipe Clear

Voir l’ensemble des LED Light Pipes

Sous-total (1 sachet de 100 unités)*

182,90 €

(TVA exclue)

221,30 €

(TVA incluse)

Add to Basket
sélectionner ou taper la quantité
Temporairement en rupture de stock
  • Expédition à partir du 04 mai 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité
Prix par unité
Le Sachet*
100 +1,829 €182,90 €

*Prix donné à titre indicatif

N° de stock RS:
170-7639
Référence fabricant:
1296.2012
Fabricant:
Mentor GmbH
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout

Marque

Mentor GmbH

Product Type

LED Light Pipe

Flexible/Rigid

Rigid

Length

11.85mm

Orientation

Right Angle

Mount Type

Press-In

Number of Ways

20

LED Included

No

Lens Colour

Clear

Number of Light Pipes

20

Light Pipe Shape

Dome

Outside Diameter

1.95 mm

Standards/Approvals

UL94

Configuration Rows x Columns

2 x 1

Pays d'origine :
DE

Horizontal Light Guides, 2 Row - Round


This family of horizontal light guides, from MENTOR, consist of two rows of light pipes. The round heads are available in 2 mm or 3 mm diameters and are parallel to the printed board on the front panel. This range of light guides is available in single column or multiple column arrays with up to 20 heads. Some of the light guides within this range use a screen to prevent radiation when using a combination of different colours.

Horizontal light pipes are designed for use with surface mount (SMD) LEDs and are fitted to the circuit board using push-fit lugs. The light pipe inject face sits in close proximity to the LED on the board.

Features of the horizontal light guides:

Round heads

2 x rows

1 to 10 columns

Clear plastic package

Ambient temperature: -40°C to +85°C

LED Light Pipes, MENTOR - Horizontal


MENTOR light guides are designed to transmit light from a PCB-mounted LED to the desired user interface. This transfer is completed with little or no loss of luminance and no light bleed between adjacent elements.

This vast range of light guides are available in single or multiple light guide options, with a range of head shapes and sizes. These options allow them to provide a solution for all sorts of applications. They also offer simple installation and high ESD protection.
