MEAN WELL IP65, IP67 LED Driver, 48V, 150 W, 3.2A, 6.25 A Additive 0 to 10 V dc or 10V PWM Signal
- N° de stock RS:
- 106-598
- Numéro d'article Distrelec:
- 301-34-615
- Référence fabricant:
- ELG-150-48
- Fabricant:
- MEAN WELL
Sous-total (1 unité)*
35,10 €
(TVA exclue)
42,47 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Temporairement en rupture de stock
- 14 unité(s) expédiée(s) à partir du 05 octobre 2026
- Plus 16 unité(s) expédiée(s) à partir du 02 novembre 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 1 + | 35,10 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 106-598
- Numéro d'article Distrelec:
- 301-34-615
- Référence fabricant:
- ELG-150-48
- Fabricant:
- MEAN WELL
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | MEAN WELL | |
| Product Type | LED Driver | |
| Output Voltage | 48V | |
| Maximum Output Power | 150W | |
| Input Voltage | 100, 305V | |
| Dimming Operation | Additive 0 to 10 V dc or 10V PWM Signal | |
| Input Voltage Type | AC/DC | |
| IP Rating | IP65, IP67 | |
| Operating Modes | Constant Current/Constant Voltage | |
| Driver Current | 3.2, 6.25A | |
| LED Voltage | 24V | |
| Series | ELG-150 | |
| Standards/Approvals | BISIS15885, BS EN/EN62384, CSA C22.2 No. 250.13-12, EAC TP TC 004, GB19510.1, GB19510.14, IEC/BS EN/ES/NZS 61347-1, IEC/BS EN/ES/NZS 61347-2-13, IS 15885(Part 2/Sec13), KC61347-1, KC61347-2-13, R-41027766, UL8750 | |
| Primary Type | LED Driver | |
| Sélectionner tout | ||
|---|---|---|
Marque MEAN WELL | ||
Product Type LED Driver | ||
Output Voltage 48V | ||
Maximum Output Power 150W | ||
Input Voltage 100, 305V | ||
Dimming Operation Additive 0 to 10 V dc or 10V PWM Signal | ||
Input Voltage Type AC/DC | ||
IP Rating IP65, IP67 | ||
Operating Modes Constant Current/Constant Voltage | ||
Driver Current 3.2, 6.25A | ||
LED Voltage 24V | ||
Series ELG-150 | ||
Standards/Approvals BISIS15885, BS EN/EN62384, CSA C22.2 No. 250.13-12, EAC TP TC 004, GB19510.1, GB19510.14, IEC/BS EN/ES/NZS 61347-1, IEC/BS EN/ES/NZS 61347-2-13, IS 15885(Part 2/Sec13), KC61347-1, KC61347-2-13, R-41027766, UL8750 | ||
Primary Type LED Driver | ||
Statut RoHS : Exempté
- Pays d'origine :
- CN
The MEANWELL AC-DC Single output LED Driver mix mode with PFC, providing an output of 48Vdc at 3.13A. With a durable metal housing and IP67 rating, this driver ensures reliable performance in various applications.
Mix mode (CV+CC) with PFC for efficient operation
Output of 48Vdc at 3.13A for consistent power supply
Durable metal housing and IP67 rating for robustness
Wide input voltage range of 100-305V for versatility
Constant Current (C.C.) and Constant Voltage (C.V.) operation for stability
