RS PRO Fibreglass Bag Filter, F9 Grade w: 287 mm h: 592 mm d: 292 mm

N° de stock RS:: 194-7667
Fabricant:: RS PRO

RS PRO Fibreglass Bag Filter, F9 Grade w: 287 mm h: 592 mm d: 292 mm

Sous-total (1 paquet de 2 unités)*

186,25 €

(TVA exclue)

225,362 €

(TVA incluse)

Frais de livraison offerts pour toute commande de plus de 90,00 €

En stock

12 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution

Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails

Unité	Prix par unité	le paquet*
2 +	93,125 €	186,25 €

*Prix donné à titre indicatif

N° de stock RS:: 194-7667
Fabricant:: RS PRO

Spécifications

Documentation technique

Législations et de normes

Détails du produit

Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.

Sélectionner tout	Attribut	Valeur
	Marque	RS PRO
	Product Type	Bag Filter
	Filter Type	Bag
	Media Area	9.5m²
	Number of Pockets	4
	Filter Grade	F9
	Maximum Air Flow	2250m³/h
	Initial Pressure Drop	140Pa
	Final Pressure Drop	450Pa
	Actual Depth	292mm
	Actual Height	592mm
	Actual Width	287mm
	Case Material	ABS
	Standards/Approvals	EN, RoHS
	Media Material	Fibreglass
	Header Size	25mm
	Nominal Height	592mm
	Nominal Width	287mm
	Nominal Depth	292mm

	Sélectionner tout
	Marque RS PRO
	Product Type Bag Filter
	Filter Type Bag
	Media Area 9.5m²
	Number of Pockets 4
	Filter Grade F9
	Maximum Air Flow 2250m³/h
	Initial Pressure Drop 140Pa
	Final Pressure Drop 450Pa
	Actual Depth 292mm
	Actual Height 592mm
	Actual Width 287mm
	Case Material ABS
	Standards/Approvals EN, RoHS
	Media Material Fibreglass
	Header Size 25mm
	Nominal Height 592mm
	Nominal Width 287mm
	Nominal Depth 292mm

Pays d'origine :: GB

RS PRO Bag Filter

RS PRO introduces the glass fibre bag filter designed for maximum strength and optimal airflow. Constructed from high capacity glass fibre and bonded into an ABS moulded plastic case this rigid bag filter has been engineered by RS PRO to deliver longer life and reduced energy consumption than other types of bag filters. This HVAC filters compact configuration can be retrofitted for all bag filters grade M6 to F9.

Features and Benefits

Manufactured from high-quality glass fibre and ABS plastic to ensure the durability and long life of the filter

Totally stable media presentation to the air

Will not collapse during downtime due to the rigid design

Will always operate at 100% of capacity

Fully incinerable

Extended media Area

Low-Pressure Drop

High Capacity

Available with 20mm or 25mm Header

Long-life retrofit for any standard bag filter

Applications

HVAC air filters are used for clarification and filtration of the air passing through them removing pollen, dust and even pet hair. They can be used in both household and industrial spaces in heating, ventilation and air conditioning (HVAC) systems to improve air quality by removing unwanted particles from the air.

How do air filters work?

Used in heating, ventilation and air conditioning, HVAC filters are generally made of gauze-like material. This provides a small passage for air to flow through whilst also stopping larger particles. Standard air filters are designed with efficiency in filtration, as they collect debris and dust. Some more complex filters remove odours and feature a charcoal element. Preventing debris from entering ventilation, cooling or heating system is vital in ensuring longevity as foreign objects in these types of systems can cause them to overheat and cease functioning.

Why change HVAC air filters?

If these types of filters are not properly attended to, they can become clogged. This can prevent air flow possibly causing the system to overheat and can eventually lead to equipment break down or fires. Changing air filters regularly is vital for health and safety and a HVAC systems longevity.
