Phoenix Contact QUICKON Series RJ45 Connector Male, Cable, Cat5 Shielded Straight 1 Port 4 Way
- N° de stock RS:
- 921-0102
- Référence fabricant:
- 1403366
- Fabricant:
- Phoenix Contact
Bénéficiez d'une remise sur les achats en gros
Ajoutez 10 de plus pour économiser 4%
Consulter les options de prix de grosSous-total (1 unité)*
49,59 €
(TVA exclue)
60,00 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
Stocké-e par le fabricant
- Prêt à être expédié à partir du 04 janvier 2027
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | Économie |
|---|---|---|
| 1 - 9 | 49,59 € | - |
| 10 - 19 | 47,51 € | 4% |
| 20 - 49 | 45,48 € | 8% |
| 50 - 99 | 43,39 € | 12% |
| 100 + | 41,36 € | 16% |
*Prix donné à titre indicatif
- N° de stock RS:
- 921-0102
- Référence fabricant:
- 1403366
- Fabricant:
- Phoenix Contact
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Phoenix Contact | |
| Product Type | RJ45 Connector | |
| Ethernet Connector Type | RJ45 | |
| LAN Category | Cat5 | |
| Number of Ports | 1 | |
| Mount Type | Cable | |
| Number of Ways | 4 | |
| Connector Gender | Male | |
| Connector Type | Plug | |
| Shield Type | Shielded | |
| Orientation | Straight | |
| IP Rating | IP67, IP65 | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | IDC | |
| Maximum Operating Temperature | 70°C | |
| Hazardous Area Certification | No | |
| Standards/Approvals | No | |
| Length | 68.8mm | |
| Series | QUICKON | |
| Width | 22mm | |
| Depth | 30mm | |
| Contact Material | Copper Alloy | |
| Contact Plating | Gold over Nickel | |
| Sélectionner tout | ||
|---|---|---|
Marque Phoenix Contact | ||
Product Type RJ45 Connector | ||
Ethernet Connector Type RJ45 | ||
LAN Category Cat5 | ||
Number of Ports 1 | ||
Mount Type Cable | ||
Number of Ways 4 | ||
Connector Gender Male | ||
Connector Type Plug | ||
Shield Type Shielded | ||
Orientation Straight | ||
IP Rating IP67, IP65 | ||
Minimum Operating Temperature -40°C | ||
Termination Type IDC | ||
Maximum Operating Temperature 70°C | ||
Hazardous Area Certification No | ||
Standards/Approvals No | ||
Length 68.8mm | ||
Series QUICKON | ||
Width 22mm | ||
Depth 30mm | ||
Contact Material Copper Alloy | ||
Contact Plating Gold over Nickel | ||
- Pays d'origine :
- DE
RJ45 Quickon Connector Inserts
From Phoenix Contact, a series of push pull connector inserts from the QUICKON range of RJ45 connectors. These RJ45 connectors have IDC fast connect terminals with copper alloy contacts. This professional range of RJ45 connectors all have diecast zinc housings (apart from stock number 921-0183) which has PA-GF housing material. The RJ45 connector inserts are available in 4 and 8 position options have an external cable diameter from 5 mm to 8 mm. Part number 921-0102 has metal EMC shielding. Part number 921-0183 is also 1 Gbit/s.
