Molex 93627 Series RJ45 Connector Female, Panel Mount Shielded Right Angle 2 Port 8 Way
- N° de stock RS:
- 193-5927
- Référence fabricant:
- 93627-3608
- Fabricant:
- Molex
Sous-total (1 plateau de 56 unités)*
357,45 €
(TVA exclue)
432,49 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- 224 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | le plateau* |
|---|---|---|
| 56 + | 6,383 € | 357,45 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 193-5927
- Référence fabricant:
- 93627-3608
- Fabricant:
- Molex
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Molex | |
| Product Type | RJ45 Connector | |
| Ethernet Connector Type | RJ45 | |
| Mount Type | Panel Mount | |
| Number of Ports | 2 | |
| Number of Ways | 8 | |
| Connector Gender | Female | |
| Connector Type | Jack | |
| Shield Type | Shielded | |
| Orientation | Right Angle | |
| Magnetic | Yes | |
| LED | Yes | |
| Minimum Operating Temperature | 0°C | |
| Light Pipes | No | |
| Termination Type | Solder | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | No | |
| Length | 15.76mm | |
| Hazardous Area Certification | No | |
| Width | 14.1mm | |
| Series | 93627 | |
| Depth | 21.4mm | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold over Nickel | |
| Sélectionner tout | ||
|---|---|---|
Marque Molex | ||
Product Type RJ45 Connector | ||
Ethernet Connector Type RJ45 | ||
Mount Type Panel Mount | ||
Number of Ports 2 | ||
Number of Ways 8 | ||
Connector Gender Female | ||
Connector Type Jack | ||
Shield Type Shielded | ||
Orientation Right Angle | ||
Magnetic Yes | ||
LED Yes | ||
Minimum Operating Temperature 0°C | ||
Light Pipes No | ||
Termination Type Solder | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals No | ||
Length 15.76mm | ||
Hazardous Area Certification No | ||
Width 14.1mm | ||
Series 93627 | ||
Depth 21.4mm | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold over Nickel | ||
- Pays d'origine :
- CN
MXMag Gigabit Ethernet 8 Core Non-PoE Single-Port RJ45 Connector, 21.40mm Depth, 3.30mm Phy Pin Length, Right-Angle, Inverted Profile, with Shield Tabs, with Green/Yellow-Green/Yellow LEDs, Standard Temperature, with 2kV Shield Connection, Tray.
