HARTING IX Industrial Series IX Industrial Connector Female, PCB, PCB, Cat6a, Cat6a Shielded Angled, Angled 1 Port 10
- N° de stock RS:
- 178-4183
- Référence fabricant:
- 09452812560
- Fabricant:
- HARTING
Indisponible
RS n'aura plus ce produit en stock.
- N° de stock RS:
- 178-4183
- Référence fabricant:
- 09452812560
- Fabricant:
- HARTING
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | HARTING | |
| Product Type | IX Industrial Connector | |
| Ethernet Connector Type | IX Industrial, IX Industrial | |
| LAN Category | Cat6a, Cat6a | |
| Number of Ports | 1 | |
| Mount Type | PCB, PCB | |
| Number of Ways | 10 | |
| Connector Gender | Female | |
| Connector Type | Jack | |
| Shield Type | Shielded | |
| Orientation | Angled, Angled | |
| IP Rating | IP20, IP20 | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Depth | 11.65mm | |
| Width | 9.4mm | |
| Hazardous Area Certification | No | |
| Length | 8.8mm | |
| Standards/Approvals | No | |
| Series | IX Industrial | |
| Contact Material | Copper Alloy, Copper Alloy | |
| Contact Plating | Gold, Gold | |
| Sélectionner tout | ||
|---|---|---|
Marque HARTING | ||
Product Type IX Industrial Connector | ||
Ethernet Connector Type IX Industrial, IX Industrial | ||
LAN Category Cat6a, Cat6a | ||
Number of Ports 1 | ||
Mount Type PCB, PCB | ||
Number of Ways 10 | ||
Connector Gender Female | ||
Connector Type Jack | ||
Shield Type Shielded | ||
Orientation Angled, Angled | ||
IP Rating IP20, IP20 | ||
Termination Type Solder | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Depth 11.65mm | ||
Width 9.4mm | ||
Hazardous Area Certification No | ||
Length 8.8mm | ||
Standards/Approvals No | ||
Series IX Industrial | ||
Contact Material Copper Alloy, Copper Alloy | ||
Contact Plating Gold, Gold | ||
PCB connector, Angled, Solder termination, Rated current: 1.5A, LCP, Black, Contacts: 8, + 2x GND, Copper alloy, Au over Ni
Ethernet-Data jack suitable for
industry
Compact and robust design
360° shielding
Category of transmission Cat. 6A
5000 mating cycles
70 % reduced size compared to
RJ45
