Microchip, 64 kB Serial EEPROM, 230 ns 8-Pin SOIC Serial-SPI
- N° de stock RS:
- 197-6058P
- Référence fabricant:
- 25LC640-I/P
- Fabricant:
- Microchip
Offre groupée disponible
Sous-total 100 unités (conditionné en tube)*
86,50 €
(TVA exclue)
104,70 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 75,00 €
Temporairement en rupture de stock
- 200 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité |
|---|---|
| 100 + | 0,865 € |
*Prix donné à titre indicatif
- N° de stock RS:
- 197-6058P
- Référence fabricant:
- 25LC640-I/P
- Fabricant:
- Microchip
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | Microchip | |
| Memory Size | 64kB | |
| Product Type | Serial EEPROM | |
| Interface Type | Serial-SPI | |
| Package Type | SOIC | |
| Mount Type | Through Hole | |
| Pin Count | 8 | |
| Maximum Clock Frequency | 3MHz | |
| Organisation | 8K x 8 bit | |
| Minimum Supply Voltage | 2.5V | |
| Number of Bits per Word | 8 | |
| Maximum Supply Voltage | 5.5V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Height | 3.3mm | |
| Series | 25LC640 | |
| Standards/Approvals | No | |
| Width | 6.35 mm | |
| Length | 9.4mm | |
| Supply Current | 1mA | |
| Data Retention | 200year | |
| Maximum Random Access Time | 230ns | |
| Number of Words | 8K | |
| Automotive Standard | No | |
| Sélectionner tout | ||
|---|---|---|
Marque Microchip | ||
Memory Size 64kB | ||
Product Type Serial EEPROM | ||
Interface Type Serial-SPI | ||
Package Type SOIC | ||
Mount Type Through Hole | ||
Pin Count 8 | ||
Maximum Clock Frequency 3MHz | ||
Organisation 8K x 8 bit | ||
Minimum Supply Voltage 2.5V | ||
Number of Bits per Word 8 | ||
Maximum Supply Voltage 5.5V | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Height 3.3mm | ||
Series 25LC640 | ||
Standards/Approvals No | ||
Width 6.35 mm | ||
Length 9.4mm | ||
Supply Current 1mA | ||
Data Retention 200year | ||
Maximum Random Access Time 230ns | ||
Number of Words 8K | ||
Automotive Standard No | ||
- Pays d'origine :
- TH
Microchip 25LC640-I/P is a 64 Kbit Serial Electrically Erasable PROM [EEPROM]. The memory is accessed via a simple Serial Peripheral Interface (SPI) compatible serial bus. The bus signals required are a clock input (SCK) plus separate data in (SI) and data out (SO) lines. Access to the device is controlled through a Chip Select (CS) input. Communication to the device can be paused via the hold pin (HOLD).
Low-Power CMOS Technology, Write current: 3 mA, typical, Read current: 500 μA, typical, Standby current: 500 nA, typical
8192 x 8 Bit Organization
Self-Timed Erase and Write Cycles
Block Write Protection, Protect none, 1/4, 1/2 or all of array
Built-in Write Protection, Power on/off data protection circuitry, Write enable latch, Write-protect pin
Sequential Read
High Reliability, Data retention: > 200 years, ESD protection: > 4000V
8-pin PDIP, SOIC and TSSOP Packages
Temperature Ranges Supported: Industrial (I): -40°C to +85°C, Automotive (E): -40°C to +125°C
